- Page 1 HP246PFB (HSG1459) LCD Monitor...
- Page 2 Low Voltage Directive 2014/35/EU and RoHS Directive 2011/65/EU. Socket-outlet shall be near the equipment and shall be accessible. Trademark Notice: HANNspree products incorporate High-Definition Multimedia Interface (HDMI™) technology. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
- Page 3 User’s Manual RECYCLING INFORMATION We, at HANNspree care very much about our environment protection strategy and firmly believe that it helps us have Ahealthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be Recycled and re-integrated into brand-new marvels.
-
Page 4: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ....................5 PRECAUTIONS....................5 SPECIAL NOTES ON LCD MONITORS ............6 BEFORE YOU OPERATE THE MONITOR ............7 FEATURES......................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 INSTALLATION INSTRUCTIONS ..............8 POWER....................... 8 SETTING THE MONITOR ON THE WALL .......... -
Page 5: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 6: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. -
Page 7: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 61,13cm / 24” Wide Screen TFT Color LCD Monitor Crisp, Clear Display Ergonomic Design Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: LCD Monitor Cables and User manual Power Adaptor... -
Page 8: Installation Instructions
User’s Manual INSTALLATION INSTRUCTIONS INSTALL REMOVE Figure.1. Installing and Removing the Base POWER POWER SOURCE: 1. Make sure that the power cord is the correct type required in your area. 2. This LCD monitor has an Internal universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required.) 3. -
Page 9: Setting The Monitor On The Wall
*Installing the LCD Monitor requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. HANNspree bears no responsibility for improper mounting or mounting that results in accident or injury. You can ask a... -
Page 10: Making Connections
User’s Manual MAKING CONNECTIONS CONNECTING TO A PC You can setup your monitor with the below suggested connections. Ensure your monitor is off during this process. 1. Connect one end of the HDMI cable to the back of the monitor and connect the other end to the computer’s HDMI port. -
Page 11: Adjusting The Viewing Angle
User’s Manual ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you do not topple the monitor when you change the monitor’s angle. ... -
Page 12: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 13: Front Panel Control
User’s Manual FRONT PANEL CONTROL Power Button: Press this button to switch ON/OFF of monitor’s power. Power Indicator: Blue — Power On mode. — Power Saving mode. MENU / ENTER: Turn the OSD menu on or used as《confirmation》function during start-up . Adjust ▲▼: ... -
Page 14: How To Adjust A Settings
User’s Manual HOW TO ADJUST A SETTINGS BRIGHTNESS/ CONTRAST Adjust the brightness value of the display according to your preference. Select「BRIGHTNESS」option to adjust the BRIGHTNESS brightness value. Adjust the contrast value of the display according to your preference. Select「CONTRAST」option to adjust the contrast CONTRAST value. - Page 15 User’s Manual When the aspect ratio of screen is distorted, you may make adjustments by using this function. 「 WIDE」indicates full screen display, which does not ensure the image is shown as is or in IMAGE RATIO initial scale. 「4:3」 indicates scaling by the proportion of original images, which may cause the screen showing black bands.
- Page 16 User’s Manual Select the「RESET」option to reset to the monitor’s default RESET setting. This will erase the current settings. OTHERS Select the 「INPUT SETTING」 option to change between analog INPUT (VGA) or Digital (HDMI) source. Enter the option and select Analog or Digital. While transferring via the HDMI port, it is recommended to set AUDIO INPUT to HDMI;...
- Page 17 User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
-
Page 18: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position. Power LED is not on *Power Cord should be connected. *Check if the PC system is Plug & Play compatible. *Check if the Video Card is Plug &... - Page 19 60cm / 23.6” (16:9) 60,5cm / 23.8 (16:9) 70cm / 27.5” (16:10) 1920×1200@60Hz 1920×1200@50Hz And if you still have display problem after doing the above procedure, please visit HANNspree support and Service Website: http://www.hannspree.eu/en/monitors Windows is a registered trademark of Microsoft Corporation.
-
Page 20: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED: 1. Check that the signal-cable is properly connected, if the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. - Page 21 User’s Manual (Video mode) MODE RESOLUTION 640×480p @60Hz 720×480i @60Hz 720×480p @60Hz 720×576i @50Hz 720×576p @50Hz 1280×720p @60Hz 1920×1080i @50Hz 1920×1080i @60Hz 1920×1080p @50Hz 1920×1080p @60Hz ** We ensure that the monitor can be lighted under interlace signal mode, but we can not guarantee the image quality.
-
Page 22: Appendix
3.45 kg (7.6lb) *** The above specification is subject to actual product specification and is subject to change without prior notice. NOTES: The Maximum Resolution will depends on the display card supporting. Related issue can refer to http://www.hannspree.eu/en/monitors / FAQ section.
