- Page 1 TOR LAP BELT User Manual UI12348 Instructions for fitting and use...
- Page 2 If you have any questions about your equipment, please contact us. Once again, thank you for placing your confidence in our products! Safe vehicle adaptation solutions For your safety BraunAbility products are designed and tested according to current directives and standards.
- Page 3 Safety information Limitation of use General guidance Before installing and using the lap belt occupant restraint Fit and use Fit and use - TOR Lap Belt - occupant restraint Figures After care Equipment storage and maintenance Warranty ”Declaration of conformity” at the end of the manual.
-
Page 4: Safety Information
Occupant restraints Safety information Limitation of use The development of BraunAbility kits is a continuous process. Applications are added on a regular basis. For more details contact BraunAbility or look on the BraunAbility website. - Page 5 Occupant restraints T-LBS...
-
Page 6: General Guidance
Occupant restraints General guidance • Wheelchair Accessories that have not been approved by the Wheelchair Manufacturer must be removed from the wheelchair and secured in the vehicle during transport to reduce the potential for injury. Refer to ‘Instructions For Use in Transport’ provided with the wheelchair or contact wheelchair manufacturer for further guidance. - Page 7 Anchorages should not be installed into unsound materials such as corroded metal, wood, plastic and fibre glass panels, without additional and suitable reinforcement. • The equipment has been tested in a configuration recommended by BraunAbility and any deviation from the recommendations here is the responsibility of the installer/user.
- Page 8 Occupant restraints Before installing and using the TOR Lap Belt - occupant restraint • Ensure that the wheelchair is correctly maintained and that the settings of any adjustable parts are made according to ‘Instructions for Use in Transport’. • Whenever possible remove any items of luggage etc that may be attached to the wheelchair and secure or store separately during transport in order to reduce the potential for injury to other passengers traveling in the vehicle.
- Page 9 Occupant restraints • Wheelchair users, their carers and family are advised to check vehicle specifications to ensure that sufficient floor space is available to accommodate the wheelchair and tie-down system. These distances are based upon the desire to maintain clear zones for potential head excursions of occupants provided with both upper and lower torso restraints.
- Page 10 Occupant restraints • BraunAbility recommends the use of a 3-point occupant restraint system to provide greater protection in case of an impact. However, we also recognize that some vehicle layout/designs or specific postural or medical conditions do not allow certain styles of seatbelts to be used easily. This system is not ISO 10542 compliant if used in a 2 point configuration.
- Page 11 Occupant restraints Fit and use TOR Lap Belt - occupant restraint Wheelchair tie-downs (not supplied with this restraint) should be fitted first. Removing the TOR Lap Belt Connect the buckle of the lap belt with tongue to the wheelchair retractor’s Disconnect the buckle from the tongue, (Fig.
- Page 12 Occupant restraints Figures Figure 1 MATERIAL DRAWN BY DATE CONFIDENTIAL PROPRIETARY INFORMATION DO NOT COPY WITHOUT PERMISSION OF MATERIAL SPEC APPROVED BY DATE MARTOCK, SOMERSET TA12 6EY FINISH DIMENSIONS ARE IN MILLIMETER FOR DIMENSIONS NOT SHOWN SEE CAD DATA. UNSPECIFIED TOLERANCES: CAD DATA IS BASIC.
- Page 13 Occupant restraints Wheelchair reference plane Rear securement points 30° 45° 300mm 10° (12in) 10° REAR VIEW SIDE VIEW NOTE Note that angles indicated are obtained by projecting the angle of each tie-down strap onto a vertical plane parallel to the wheelchair reference plane (side view) or onto a vertical plane that is perpendicular to the wheelchair reference plane (rear view).
- Page 14 • If the vehicle is involved in an accident when any restraints are deployed, remove them from service and replace immediately. If in doubt please contact BraunAbility.
-
Page 15: Warranty
BraunAbility products when used in conjunction with such jointly tested systems. For further details on specific applications please contact the Sales Office. In other situations, using BraunAbility products, for which BraunAbility has not participated in a joint test program, a limited BraunAbility warranty will apply. -
Page 16: Declaration Of Conformity
Directives, Standards and Regulations / BraunAbility UK Ltd Unwin House Reg 107 The Horseshoe Coat Road DIN 75078 Martock, Somerset, TA12 6EY, BraunAbility, (insert date of publishing) Phone: +44 1935 827740 Email: info@braunability.eu www.braunability.eu Declares that the products / T-LBS... - Page 17 Accredited by URS as testing laboratory in accordance with ISO/IEC 17025:2005 Quality system certified in accordance with ISO 9001:2008 Illustrations, descriptions and specifications in the user manual are based on current product information. BraunAbility UK Ltd reserves the right to make alterations without previous notice. © 2020 BraunAbility UK Ltd...
- Page 18 BraunAbility UK Ltd Unwin House Phone: +44 1935 827740 The Horseshoe, Coat Road Email: info@braunability.eu Martock, Somerset, TA12 6EY, www.braunability.eu...
