- Page 1 2022-2023 Edition SnapTable PRO ® Hyper-Lite Manual swensonshear.com Tech Support: 877-588-8748, option 2...
-
Page 2: Table Of Contents
Table of Contents Read the entire manual before attempting to operate this piece of equipment. SnapTable PRO Hyper-Lite setup precautions SnapTable PRO Hyper-Lite setup General maintenance Warranty information Specifications Trailer registration How to prepare notching station for use How to use the notchers... - Page 3 SnapTable PRO Hyper-Lite Manual Cutter Max Cut: 60” Notching O set: 29” Hemmer Max Cut: 60” Panel Sizes: 12” - 24” The SnapTable PRO Features: STANDING SEAM NOTCHER PANEL CUTTER EAVE & VALLEY HEMMER...
-
Page 4: Snaptable Pro Hyper-Lite Setup Precautions
SNAPTABLE PRO HYPER-LITE SETUP When you receive your SnapTable PRO Hyper-Lite you will also receive a components box that has all the loose parts that you will need to install onto your SnapTable PRO Hyper-Lite before you use your SnapTable PRO Hyper-Lite. -
Page 5: General Maintenance
WARRANTY - All tools are covered by a 2-year manufacturers’ warranty. The warranty does not cover normal wear and tear. Any attempt to modify the SnapTable PRO Hyper-Lite, not advised to do so by tech support, will void warranty. Using the wrong profile will result in damaging your notchers and will void the warranty. -
Page 6: How To Prepare Notching Station For Use
7. Adjust the white guide rollers on the four corners of the SnapTable PRO Hyper-Lite inward toward the panel. Guide rollers should be touching panel to keep it on track. Tighten the bolts. - Page 7 How To Use Notching Component 1. Adjust the width of the notching table using the front wheel to match your panel width. The dies should be directly over the ribs. 2. Set notchers to the desired slope using degree indicator on the operator side of the machine. 3.
-
Page 8: Adjusting The Slitter Blade
How To Use The Slitting Component AFTER THE PANEL IS NOTCHED 1. Park the slitter blade on the side of the table opposite your position. NEVER push slitter blade across the panel to shear, ALWAYS pull slitter across the panel towards you. 2. -
Page 9: How To Adjust The Shoes
How To Use Hemmer Component Clamping Handle Rotating Arm AFTER THE PANEL IS NOTCHED AND CUT 1. Slide notched panel down to the hemmer station. 2. Make sure the station is set to the appropriate slope. 3. Slightly lift the operator handle at the top to allow the panel to hit the back of the fencing of the hemmer bar. 4. - Page 10 Rotate the Hemmer to 180 degrees for trailing edge hems. What if I do multiple profiles? One set of notchers are included with each SnapTable PRO Hyper-Lite purchase. Additional notchers are available to accommodate multiple profiles. What if I need to close the rib of the standing seam panel? Follow these steps to create your tab over: •...
-
Page 11: Hip And Valley O Set Chart
Hip and Valley O set Chart Select column on top representing the panel coverage width in inches. Select the slope of the roof in the left column. Match row and column to find the o set required on the SnapTable ruler for the angle desired. Move notcher pointer to the calculated o set number on the SnapTable ruler. - Page 12 04/2022 swensonshear.com 877-588-8748 support@swensonshear.com...
