Summary of Contents for BONT ATHENA
- Page 1 ASSEMBLY & MOUNTING INSTRUCTIONS...
- Page 2 This plate has not been tightened. Please make sure you adjust all nuts and screws to match your desired skating style before using. Bont is not liable for any damage to you or your equipment if you have not tightened before skating on them.
- Page 3 Locating the center of the widest point of the sole (ball of foot) by measuring an Once you have checked all mounting hardware for tightness, break off the extra length of equal distance from both sides to the center, and place a mark. (Bont boots may the bolts...
- Page 4 #18 pivot cup Available Hardness: 78A Purple (Super Soft) Note: should just be visable above #9 action nut 83A Blue (Soft) 88A Black (Medium) 93A Red (Hard) The Athena plate assembly video can be found at www.youtube.com/bontquadskates...
- Page 5 RECOMMENDED PIVOT ADJUSTMENT TOE STOPPER Loosen the #16 pivot pin locking nut with a wrench Screw the #20 toe stopper into the toe stopper hole and adjust height to your skating style Adjust the #17 pivot pin in or out with a wrench until this is inserted properly and exerting Lock it in place with #19 toe stop locking screw slight pressure into the #18 pivot cup IMPORTANT: There should be space between #16 pivot pin locking nut and #17 pivot pin.
-
Page 6: Warranty
(including ramp skating) or jumping. Do not use any non Bont parts in the assembly of this plate. The use of non Bont parts in the plate which result in plate damage are not covered under the warranty of this plate. - Page 7 KEEP UP TO DATE WITH ALL THINGS BONT @bont_rollerskates /QuadRollerDerby BontQuadSkates We hope you love your new Bont roller skate plate!
