Summary of Contents for SWENSON SHEAR SnapTable PRO
- Page 1 2019-2020 Edition SnapTable PRO ® Manual swensonshear.com 877-588-8748...
- Page 2 Hemmer Max Angle: 60” Panel Sizes: 12” - 24” Table of Contents Read the entire manual before attempting to operate this piece of equipment. SnapTable PRO setup precautions How to use the notchers Hemmer component SnapTable PRO setup How to set the notchers to...
- Page 3 SNAPTABLE PRO SETUP When you receive your SnapTable PRO you will also receive a components box that has all the loose parts that you will need to install onto your SnapTable PRO before you use your SnapTable PRO.
- Page 4 WARRANTY - All tools are covered by a 2-year manufacturers’ warranty. The warranty does not cover normal wear and tear. Any attempt to modify the SnapTable PRO, not advised to do so by tech support, will void warranty. Using the wrong profile will result in damaging your notchers and will void the warranty.
- Page 5 1. Loosen the T-Handles at the front of the table, and under the ruler, table to allow notcher travel and rail width adjustment. 2. Loosen the white plastic guide discs on the four corners of the SnapTable PRO and move them inward on the slots until they fit against your panel.
- Page 6 How To Use Notching Component 1. Adjust the width of the notching table using the front wheel to match your panel width. The dies should be directly over the ribs. 2. Set notchers to the desired slope using degree indicator on the operator side of the machine. 3.
- Page 7 How To Use The Slitting Component AFTER THE PANEL IS NOTCHED 1. Park the slitter blade on the side of the table opposite your position. NEVER push slitter blade across the panel to shear, ALWAYS pull slitter across the panel towards you. 2.
- Page 8 How To Use Hemmer Component Clamping Handle Rotating Arm AFTER THE PANEL IS NOTCHED AND CUT 1. Slide notched panel down to the hemmer station. 2. Make sure the station is set to the appropriate slope. 3. Slightly lift the operator handle at the top to allow the panel to hit the back of the fencing of the hemmer bar. 4.
- Page 9 Rotate the Hemmer to 180 degrees for trailing edge hems. What if I do multiple profiles? One set of notchers are included with each SnapTable PRO purchase. Additional notchers are available to accommodate multiple profiles. What if I need to close the rib of the standing seam panel? Follow these steps to create your tab over: •...
- Page 10 Hip and Valley O set Chart Select column on top representing the panel coverage width in inches. Move notcher pointer to the calculated o set number on the SnapTable ruler. Select the slope of the roof in the left column. Bump notchers as necessary to correct for construction variations a ecting Match row and column to find the o set required on the SnapTable ruler for the angle of cut.
