INSTALLATION
MANUAL
Products name : KYOTO 3-HOLE BASIN MIXER
Products Applied: 589.35.002, 589.35.062, 589.35.032,
589.35.092
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the KYOTO and is the answer not in the manual?

Questions and answers

Summary of Contents for Häfele KYOTO

  • Page 1 INSTALLATION MANUAL Products name : KYOTO 3-HOLE BASIN MIXER Products Applied: 589.35.002, 589.35.062, 589.35.032, 589.35.092...
  • Page 3: Installation Notices

    I. INSTALLATION NOTICES: Install product only after completion of interior decoration in case paint and chemicals may harm product. Clean pipes and install area to get rid of mud, sand or other debris may block the pipe and harm product. Operating pressure: 1 –...
  • Page 4 III.Installation Steps(Fig.1 - 9) Prepare these tools. Sleeve wrench (supplied) Spanner Wrench (supplied) Phillips screwdriver Pick out cap by a sharp point tool, remove check Check back screw back screws, handwheels, decorative bodies, Handwheel decorative rings, hexagonal nuts and bases from two Decorative body inlet valves in turn, screw Decorative ring...
  • Page 5 Pass two inlet valves (red on left and blue on right) from down upwards through holes of basin, keep outlets of inlet valves toward the opposite, install and tighten base, then fix hexagonal nut. Outlet Outlet Remove locking nut, locking washer and rubber washer from faucet body.
  • Page 6 Connect upper lift rod and lower lift rod. Connect hoses (Torque ≤5N·m) as red (hot) on left and blue (cold) on right. Upper lift rod Hose Lower lift rod Pass faucet body from up downwards through hole of basin, pad rubber washer and Basin locking washer, fix...
  • Page 7 Connect hoses to inlet valves, tighten locking nuts and set screws on inlet valves in turn, connect lift rod with drainage set. Set screw Drainage set Pad decorative rings and tighten decorative body. Install handwheels (Note: red on left and blue on right), fix with check back screws and insert cap.
  • Page 8 After installation, flow water (hot on left and cold on right) to check if the installation is qualified. The figure displays open state of handwheels. Cold water Hot water...
  • Page 9: Hướng Dẫn Lắp Đặt

    HƯỚNG DẪN LẮP ĐẶT PRODUCT NAME - SERIES NO.: Tên sản phẩm: VÒI TRỘN 3-LỖ KYOTO Các mã sản phẩm áp dụng: 589.35.002, 589.35.062, 589.35.032, 589.35.092...
  • Page 10 LƯU Ý KHI LẮP ĐẶT: Chỉ lắp sản phẩm khi khi hoàn thành trang trí nội thất, tránh trường hợp sơn và hoá chất làm hư hại bề mặt. Làm sạch đường cấp nước và khu vực lắp đặt để tránh tắc nghẽn do bùn đất, cát hoặc chất bẩn khác.
  • Page 11 III.Installation Steps(Fig.1 - 9) Chuẩn bị những dụng cụ này Chìa vặn ống nối (Được cung cấp) Cần siết Chìa vặn (Được cung cấp) Tuốc nơ vít Phillips Tháo nắp bằng dụng cụ Nắp có đầu nhọn, tháo lần lượt Vít định vị...
  • Page 12 Đưa hai van nạp (đỏ bên trái và xanh dương bên phải) từ dưới lên trên qua lỗ bồn rửa, đặt các lỗ ra của các van nạp hướng ra phía ngược nhau, lắp và siết chặt đế, sau đó gắn đai ốc lục giác.
  • Page 13 Nối các ống mềm với các van nạp, lần lượt siết các đai ốc hãm và các vít hãm trên các van nạp, nối thanh nâng với bộ tiêu nước. Thanh nâng trên Ống mềm Thanh nâng dưới Đưa thân vòi từ trên xuống dưới qua lỗ...
  • Page 14 Nối các ống mềm với các van nạp, lần lượt siết các đai ốc hãm và các vít hãm trên các van nạp, nối thanh nâng với bộ tiêu nước. Vít hãm Bộ tiêu nước Lót các vòng trang trí và siết chặt thân trang trí.
  • Page 15 Sau khi lắp xong, để nước chảy (nóng bên trái và lạnh bên phải) để kiểm tra xem lắp đặt đúng tiêu chuẩn hay không. Hình vẽ hiển thị trạng thái mở của các tay quay. Nước lạnh Nước nóng...
  • Page 16 Häfele VN LLC. Phone: (+84 28) 39 113 113 Email: info@hafele.com.vn...
