GW Sprinkler Loflow K15 Series Manual

GW LOFLOW K-15 TYPE C, O & S

Maritime Installation of LOFLOW K15 Sprinklers:

Loflow K15 Sprinklers must be installed in the pendant position. Systems must be designed and installed in
accordance with SOLAS Regulation II-2/12, with the exception of water densities less than 5 litres/min/m
Sprinkler systems must be hydraulically calculated with the Hazen-Williams formula, to provide the
recommended minimum water pressure on the last nozzle to operate in the system. SOLAS and NFPA 750
require the systems to have standing charge of fresh water.

Installation and Maintenance:

Loflow K15 Sprinklers have a small orifice when compared with traditional sprinklers. To minimise the risk of
blocked sprinkler nozzles during operation, the sprinkler pipes must be flushed with fresh clean water through
each branch pipe end to avoid dirt in pipes before the sprinklers are installed.
Caution:
After the pipes have been flushed and the pipe plug removed, the internal pipe threads must be cleaned for any
sealing materials, before the sprinklers are installed.
The sprinklers must always be installed in the pendant position using the special purpose spanner from GW
Sprinkler A/S.

Table 1 Sprinkler Pipes and Components:

System Sprinkler material
Brass natural
Brass – chrome
Wet Pipe
Brass – ENP
Systems
Stainless steel
AISI316
Brass natural
Brass chrome
Dry Pipe Brass – ENP
Systems
Stainless steel
AISI316
The right is reserved to vary or modify any specifications without prior notice
GW SPRINKLER A/S
Kastanievej 15, DK 5620-Glamsbjerg, Denmark
TEL: +45 64722055 FAX: +45 64722255
Email: sales.dep@gwspinkler.com
Data sheet also available at www.gwsprinkler.com
GW SN030 1001 A
DATA SHEET No:
Pipe system material
Galvanized steel pipes
Cu-alloys pipes
Plastic (See note 1)
Galvanised steel pipes
Brass/Cu-alloy pipes
SS303, 304 pipes
CuNi pipes
SS316, SMO254 etc.
Plastic pipes (see note
1)
CuNi pipes
SS316, SMO254 etc.
Plastic pipes (see note
1)
Cu-alloys pipes
Brass/Cu-alloy pipes
SS303, 304 pipes
CuNi pipes
Stainless steel pipes
Data Sheet:
Page:
Issue / Date:
Extinguishing agent
Fresh water
Fresh water
Fresh & Seawater
Fresh & Seawater
Fresh water
Fresh & Seawater
Fresh & Seawater
GW Loflow K-15 Type C, O
& S
1 of
3
th
9 July 2007
2
.
