TERRACE
ASSEMBLY INSTRUCTIONS
10106 rev. A

Advertisement

loading
Need help?

Need help?

Do you have a question about the TERRACE and is the answer not in the manual?

Questions and answers

Related Manuals for sportworks TERRACE

Summary of Contents for sportworks TERRACE

  • Page 1 TERRACE ASSEMBLY INSTRUCTIONS 10106 rev. A...

  • Page 2: Table Of Contents

    Initial Release Table of Contents NOTICE ..................................2 TOOLS AND PARTS ..............................3 INSTRUCTIONS PART 1: Build Terrace Base Unit ....................8 INSTRUCTIONS PART 2: Install Bicycle Trays ......................11 APPENDIX A: Install Extension Module Frames ...................... 15 NOTICE Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or loss, whether direct, indirect, or incidental, resulting from the incorrect attachment or inappropriate placement, improper use, inadequate maintenance, or neglect of this product.

  • Page 3: Tools And Parts

    9/16” Wrench or Socket 3/4" Wrench or Socket Fasteners – Upright Frame QTY PER UPRIGHT, IMAGE DESCRIPTION SINGLE / DOUBLE SIDED* Concrete Anchor ½-13 x 2 / 2 4.25 Hex Bolt 3/8-16 x 3 ¾” 4 / 4 10106 rev. A sportworks.com...
  • Page 4 11 / 12 Fasteners – Lower Trays IMAGE DESCRIPTION QTY PER TRAY T45 Tamper-Resistant Torx Hex Bolt 3/8-16 x 7/8” 3/8” Washer Fasteners – Upper Trays IMAGE DESCRIPTION QTY PER TRAY Hex Bolt 3/8-16 x 1” 3/8” Washer 10106 rev. A sportworks.com...
  • Page 5 Parts - Single-Sided Modules QTY PER BASE MODULE IMAGE DESCRIPTION / EXTENSION MODULE Upright Frame 2 / 1 Inside Connecting Bar 1 / 1 Outside Connecting Bar 1 / 1 Cross Tube 1 / 1 10106 rev. A sportworks.com...
  • Page 6 Parts - Double Sided Modules QTY PER BASE MODULE IMAGE DESCRIPTION / EXTENSION MODULE Upright Frame 2 / 1 Inside Connecting Bar 1 / 1 Outside Connecting Bar 2 / 2 Cross Tube 1 / 1 10106 rev. A sportworks.com...
  • Page 7 Lower level, lower Level 1 Position 1 Tray position Lower level, upper Level 1 Position 2 Tray position Upper level, lower Level 2 Position 1 Tray position Upper level, upper Level 2 Position 2 Tray position 10106 rev. A sportworks.com...

  • Page 8: Instructions Part 1: Build Terrace Base Unit

    INSTRUCTIONS PART 1: Build Terrace Base Unit STEP 1: Set upright frames parallel, standing up, set at the following distances: 4 Bike Single-Sided or 8 Bike Double-Sided Module: 26.5 inches 6 Bike Single-Sided or 12 Bike Double- Sided Extension Module: 42.5 inches 8 Bike Single-Sided or 16 Bike Double- Sided Module: 58.5 inches...
  • Page 9 If installing single-sided modules, continue to STEP 4. For double-sided modules, install the outside connecting bar on the opposite side. Be careful to match the orientation of the connecting bar to what is shown in the image to the right. 10106 rev. A sportworks.com...
  • Page 10 Install cross tube using four (4) 3-3/4” long 3/8-16 hex bolts, washers, and nylock hex nuts. If assembling a single-sided module, install the cross tube such that the Sportworks logo is in the position shown. This ensures that the tray mounting holes are oriented correctly.

  • Page 11: Instructions Part 2: Install Bicycle Trays

    3/8-16 hex bolts and washers for the rear crossbar. A T45 tamper-resistant Torx screw should be used to secure the front of the tray. Continue all level 1 tray installations alternating heights between position 1 and position 2 trayswith a tray every 16”. 10106 rev. A sportworks.com...
  • Page 12 12-bike double-sided extension module, there are a quantity of two (2) level 1 position 1 trays that will be installed on each side, with a quantity of one (1) level 1 position 2 tray in the center. 10106 rev. A sportworks.com...
  • Page 13 Start with lower tier trays, then proceed to attach the upper tier trays. This will prevent the risk of hitting your head on upper trays while completing assembly. 10106 rev. A sportworks.com...
  • Page 14 Ensure the rack is in final desired position. Mount the rack to floor with 1/2-inch wedge anchors (two (2) per upright frame). Refer to the Installation Instructions (https://www.sportworks.com/assets/fil es/Installation-Instructions.pdf) document for wedge anchor instructions. Assembly is complete. For extensions, continue to Appendix A. 10106 rev. A...

  • Page 15: Appendix A: Install Extension Module Frames

    Install lower connecting bars to the first extension and add hardware just as in base modules, leaving bolts loose until after cross bars are installed. Repeat these two steps for any remaining extension modules as necessary. 10106 rev. A sportworks.com...
  • Page 16 Part 2 Step 5. If modules may be later moved, install floor anchors after bicycle tray installation. For questions or support please contact our sales and support team at: 425-483-7000 or by email: salesandsupport@sportworks.com 10106 rev. A sportworks.com...
