Summary of Contents for Memphis nanoboxx NANO110P
- Page 1 #MEMPHISAUDIO www.memphiscaraudio.com...
- Page 2 NANO110P A U D I O S I N C E 1 9 6 5 NANO110P 10” Under Seat Powered Bass System...
- Page 3 A. POWER STATUS LED F. INPUT GAIN CONTROL The LED indicator light glows GREEN when power is ON and After you’ve installed your system, turn this control to a no problems are present. If one of the protection circuits minimum. comes on, the light will change to RED Turn the head unit ON (the subwoofer will turn on via the remote connection).
- Page 4 Low-level RCA input wiring is preferred for the best audio performance. Always use a high quality RCA cable to carry the signal to your NANOBOXX for the best quality performance. Memphis Connection wires are the preferred choice to feed your system the high performance signal you need.
- Page 5 POWER CONNECTIONS Connect the ground terminal to the closest point on the chassis of the vehicle. Keep this ground wire to less than 39” in length. Use 8 gauge or heavier wire. Connect the remote terminal to the remote output of the head unit using 16 Gauge or heavier wire. Connect an empty fuse holder within 18”...
- Page 6 REMOTE LEVEL CONTROL CONNECTION FIGURE 5 NOTE: Install the remote control securely under the REMOTE LEVEL CONTROL dash in a similar location where it will not distract the driver. SPECIFICATIONS RMS POWER 180W <0.4% SIGNAL-TO-NOISE RATIO >90dB FREQUENCY RESPONSE 20Hz - 150Hz HIGH LEVEL INPUT SENSITIVITY 1.0 - 9.0v LOW LEVEL INPUT SENSITIVITY...
- Page 7 This is usually caused by a poor quality RCA cable which can pick up radiated noise. ENGINE NOISE (STATIC TYPE) We recommend Memphis Connection RCA cables. Check that the RCA grounds are not shorted to the vehicle chassis. ENGINE NOISE Check that the head unit is properly grounded.
