- Page 1 User’s Manual – A S Welding machine REBO Welding machine AR-HE-SGTIG180 Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Welding machine REBO List of contents 1. Safety instructions ..........3 1.1 General ................3 1.2 Flue gas ................3 1.3 Radiation ................ 4 1.4 Fire .................. 4 1.5 Electrical hazard ............. 4 1.6 Noise ................5 1.7 Danger of accident through supply lines ...... -
Page 3: Safety Instructions
User’s Manual – A S Welding machine REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 4: Radiation
User’s Manual – A S Welding machine REBO 1.3 Radiation • Warning! The radiation of the arc can lead to eye damage and skin burns. Do not look into the arc with unprotected eyes. Therefore, a shield or a protective helmet should be used to protect the eyes. -
Page 5: Noise
User’s Manual – A S Welding machine REBO 1.6 Noise • Warning! When used, very loud noise is generated, which permanently damages the hearing! • In continuous use, sufficient hearing protection must be worn. Use earmuffs or other aids to protect the ear. -
Page 6: Technical Specifications
User’s Manual – A S Welding machine REBO 3. Technical specifications Model AR-HE-SGTIG180 Mains connection 230 V, 50 Hz Max Input current 3.7 KVA Open circuit voltage 56 V Duty cycle 60 % Working current infinitely variable from 10 - 180 A... - Page 7 User’s Manual – A S Welding machine REBO...
-
Page 8: Use
User’s Manual – A S Welding machine REBO 1. Handle 2. ON/OFF switch 3. Controller welding current 4. Overload indicator 5. Welding delay time (in seconds) 6. Impetus switch 7. Switch electrode/hose package 8. Connection of electrode cable 9. Connection hose package 10. -
Page 9: Commissioning
User’s Manual – A S Welding machine REBO 5.4 Commissioning • After you have made all the electrical connections for the power supply and for the welding circuit, you can put the device into operation. • Switch on the device with the switch (2). •... -
Page 10: Troubleshooting
User’s Manual – A S Welding machine REBO • Wire nozzle and gas sleeve are wear parts and must be replaced from time to time (radiant heat and deposits). • When using the cutter for a longer time, you must remove the weld spatter from the gas sleeve (high heat) to prevent a short circuit (destruction of both nozzles, burner tube and rectifier possible) between contact and gas nozzle. -
Page 11: Disposal Instruction
User’s Manual – A S Welding machine REBO 8. Disposal instruction 8.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. - Page 12 Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
