Summary of Contents for i-team i-dose
- Page 1 i-dose Floor cleaning system User manual i-team Professional b.v. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Email: hello@i-teamglobal.com Internet: www.i-teamglobal.com...
- Page 2 Original user manual, written in the English Language Future Cleaning Technologies B.V. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Email: hello@i-teamglobal.com Internet: www.i-teamglobal.com Model: i-dose starter kit XL Date: 22/10/2020 Product code: K1.P.72.0081.2 Version: v.1.0...
-
Page 3: Preface
Please read the user manual carefully. Become familiar with the correct operation and maintenance procedures. Store the manual in a safe place. The manual is an essential part of the i-dose system and must be handed over to the new owner upon resale or exchange. -
Page 4: Reading Guide
Reading guide The following symbols and terms are used throughout this manual to alert the reader to safety issues and important information: Symbol Term Explanation WARNING Indicates a hazardous situation which, if the safety instructions are not followed, can lead to injuries of the operator or bystanders, light and/or moderate damage to the product or the environment. -
Page 5: Table Of Contents
Content Preface................................3 Purpose of the user manual ..........................3 Target audience ..............................3 Operators of the i-dose ............................3 Reading guide ..............................4 Introduction ............................... 7 Intended use of the product....................... 7 Non-intended use of the product ....................... 7 Lifespan ............................. - Page 6 Trouble shooting ............................21 Decommissioning and disposal ......................... 22 Attachments ............................. 23 10.1 CE Certificate ........................... 23...
-
Page 7: Introduction
1 Introduction i-dose® is an easy and safe system to use. This manual helps you get started and explains the operation and maintenance procedure. This manual is intended for those who work with the i-dose system and perform daily maintenance. -
Page 8: Specifications
The i-dose® system should only be operated with the materials supplied. Using alternative supplies may cause damage to the i-dose and may cause a risk to the operator. The use of alternative supplies voids manufacturer's warranty. The warranty period is 1 year and is only valid for the injector and... -
Page 9: Description
2 Description The i-dose® is an integrated floor cleaning solution that removes virtually any type of soil from any type of hard floor substrate. The cleaning pods feature HygeniQ Greenovation Technology that is available in four different variants: i-dose General Purpose Floor Cleaner, Restroom Floor Sanitizer, Kitchen Floor Degreasing Cleaner and Heavy Duty Synthetic Degreasing Cleaner. -
Page 10: I-Dose® Sleeves With Cleaning Pods
2.1 i-dose® sleeves with cleaning pods Figure 3 Each package contains 120 i-dose pods. Packed in 12 sleeves, each containing 10 i-dose pods. -
Page 11: Variety Pack
2.2 Variety pack Figure 4 Each variety pack contains 12 sleeves, 3 sleeves per formula, each containing 10 i-dose pods. That's a total of 120 pods. 2.3 Different types of cleaning agent Pod content color Intended use green colored cleaning agent... -
Page 12: Safety
WARNING • DO NOT touch the knives inside the injector; • DO NOT use any other type or brand of chemical pods other than the i-dose pods; • DO NOT overtighten the injector on the tank; • insert the pod in the correct orientation, with logo pointing upwards. -
Page 13: Transport And Storage
• do not carry the solution tank by the injector; • store the i-dose system in a cool and dry place; • during storage the i-dose system should be protected from frost; •... -
Page 14: Assembly And Installation
5 Assembly and installation The i-dose® system does not require much assembly as the injector is pre-installed on the solution tank. Only the pod dispenser needs to be installed. 5.1 Unboxing The i-dose system starter kit is packed in 1 box. -
Page 15: Assembly
5.2 Assembly TIP: Assemble your own mix of pods that suit your cleaning jobs. See section 2.3 for the different types of cleaning agent. 1. Place the pods (Figure 6, pos 1) into the pod dispenser (Figure 6, pos 2). Figure 6 2. -
Page 16: Operation
6 Operation ATTENTION • The i-dose system is only intended to be used in combination with the i-mop® floor scrubber family; • Always place the pod with logo pointing upwards. 1. Fill the solution tank (Figure 8, pos 1) with tap water. -
Page 17: Exchanging The Pods
Figure 10 ATTENTION There is no need to shake the solution tank as the the chemicals for the i-dose have been specially designed to disperse evenly. 6.1 Exchanging the pods 1. Open the injector top (Figure 11, pos 1). -
Page 18: Filling The Solution Tank
4. Take out the desired pod (Figure 12, pos 2). 5. Push the the solution tank back onto the i-mop body. 6. Place the pod in the pod injector with the i-dose logo facing upwards (Figure 11, pos 2). 7. Close the injector top. Figure 12 ATTENTION Dispose of the empty i-pods in an appropriate waste container for PE plastics. -
Page 19: Maintenance
7 Maintenance WARNING Before you start maintenance, replacing parts or cleaning; Turn off the i-mop® and remove the batteries. 7.1 Cleaning 7.1.1 Rinsing the injector Rinse the injector once a week under tap water. 1. Turn the injector (Figure 14, pos 1) counterclockwise to remove it from the solution tank. -
Page 20: Damaged Or Worn Parts
7.2 Damaged or worn parts Damaged or worn parts need to be replaced immediately. Contact your local i-team Global partner or visit www.i-teamglobal.com for more information. 7.3 Storage See section 4. -
Page 21: Trouble Shooting
The knives are blunt/worn out Contact your i-team partner for a replacement injector. Surface tension on the liquid Push the yellow button a few times. -
Page 22: Decommissioning And Disposal
It is the responsibility of the i-dose® owner to dispose of the product. At the end-of-life the i-dose still contains valuable resources and needs to be disposed of according to your local laws and regulations regarding recycling of electrical equipment. -
Page 23: Attachments
10 Attachments 10.1 CE Certificate... - Page 24 This document is part of the technical file of the i-dose® system and will be available upon request.
