Summary of Contents for Kora Explorer 150SB
- Page 1 KORA Electronic Concept Explorer 150SB Hybrid integrated amplifier User’s manual Kora E.C. 8 bis, rue Claude Perrault, 31000 Toulouse, France Web : www.kora.net - Email : kora@wanadoo.fr...
-
Page 2: Table Of Contents
Table of Contents Page 1 Kora Electronic Concept the Kora team Page 2 Read before use voltage installation speakers Page 3 Operating instructions connections inputs - direct monitor turning on Page 4 Starting up - start procedure - turning off... -
Page 3: Kora Electronic Concept
Firstly, here are a few words about the company and the people behind Kora before you rush off to set up : Kora Electronic Concept was created in 1990 by a small team of electronics engineers working at the time for the Aero Spatial complex in Toulouse, south-west France. - Page 4 Page 2 – it could save you a lot of trouble! Voltage Your Kora amplifier is workshop set from a fixed mains supply voltage. This voltage is marked on the rear plate of the unit. Before connecting, check that this voltage is the same as your mains supply.
-
Page 5: Operating Instructions
Page 3 Operating instructions Connections So, now you can connect the different elements of - Source inputs your system (CD, tuner etc.) to the appropriate cinch (RCA) inputs at the rear of the amplifier. These are the source inputs – they are identical. Use high quality shielded cable in order to avoid ‘parasite noise’... -
Page 6: Turning Off
Page 4 - turning on The 150 has a motorised volume control that is controlled either by the front plate buttons or by the remote control handset. It is usable from the first time you turn on the unit as well as on stand-by mode. ADVICE : Regulate your amplifier around –40dB the first time you fire up, then adjust for your own taste. -
Page 7: Trouble Shooting
This signifies a fault in the unit : please contact your dealer or Kora directly. This may happen the first time you fire up the unit and is due to the fact that the supply is not yet loaded. -
Page 8: Technical Specifications
460 x 370 x 200mm Weight 13kg Kora E.C. warrants to the original purchaser that this product shall be - guarantee free from defects in material or workmanship for two (2) years from date of original purchase. Tubes : 90 days. - Page 9 EXPLORER 150 SB functions – front/rear view Front plate 1. Power on/off selector. 2. Direct input selector. 3. Monitor selector 4. Inputs selector. 5. Increase output volume selector. 6. Decrease output volume selector. 7. Headphone socket. 8. Volume dial (in dB). Blue LED indicates selected source.
