Swivel Massage Chair
Assembly & Operating Instructions
'Restwell' is part of the Drive DeVilbiss Group
Drive DeVilbiss Healthcare Ltd
Heathfield Lane, Birkenshaw, BD11 2HW
Please read these instructions carefully before assembling or operating this
Web: www.restwell.co.uk
product. Ensure you are familiar with all of the safety and operating instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Swivel Massage Chair and is the answer not in the manual?

Questions and answers

Related Manuals for Restwell Swivel Massage Chair

Summary of Contents for Restwell Swivel Massage Chair

  • Page 1 Swivel Massage Chair Assembly & Operating Instructions ‘Restwell’ is part of the Drive DeVilbiss Group Drive DeVilbiss Healthcare Ltd Heathfield Lane, Birkenshaw, BD11 2HW Please read these instructions carefully before assembling or operating this Web: www.restwell.co.uk product. Ensure you are familiar with all of the safety and operating instructions.

  • Page 2: Table Of Contents

    The armchair may also be Restwell is a brand of Drive DeVilbiss. Drive DeVilbiss is an ISO 9001 certified company. sensitive to temperature changes. If possible, try to gradually change the environment For more details about our products please see your local dealer.

  • Page 3: Parts

    Parts Hardware 18mm M6 Bolt x 2 25mm M6 Bolt x 2 M6 Lock nut x 2 Backrest Chair legs Stool seat Nut x 10 35mm M8 Bolt x 10 M8 Washer x 12 Adjuster knob x 2 M8 Washer x 2 Spacer x 2 Chair seat Chair base...

  • Page 4: Assembly

    Chair Assembly Chair Assembly Step 1 Push 3 x nuts (6) into each chair leg (E) as far as they will go. Screw a 18mm bolt (1) into the hole on the inside of each leg (do not fully insert). Step 3 Line up a bearing support (G) with a hole in the chair base (F) and push in, enough for it to lock.
  • Page 5 Chair Assembly Chair Assembly Step 6 Step 5 a: With help, slide the seat assembly into position on the base unit. The two pins on the end of each inner armrest (C) slide into the holes on the front of the legs ( E). Slide the spacer (9) over the pin on the underside of the seat (B), make sure that the slot b: Position the inner armrests (C) on top of the legs (E), secure each inner armrest in fits over the bar, slide on the washer (8).
  • Page 6 Chair Assembly Chair Assembly Step 8 Connect the black connector coming from the handset ( L) to the black connector on the seat and store in the handset holder (H). Stool Assembly Step 7 Step 9 a: Wrap the handset holder (H) around the inner armrest and secure will the velco strip. Push 2 x nuts (6) into each stool leg (J) as far as they will go.
  • Page 7 Stool Assembly Stool Assembly Step 10 Push the 6 x feet (14) into the holes in the underside of the stool base ( K). Step 12 Place the leg assembly onto the underside of the stool seat ( I), line up the holes and attach each leg (J) using 2 x 16mm bolts (10).

  • Page 8: Massage Chair Functions

    Massage Chair Functions Massage Chair Functions • Press the AUTO button to switch the automatic mode cycle function off, which stops the unit from changing massage mode every minute. Press the AUTO button to switch POSITION lights on the automatic mode cycle function. The AUTO light is lit when the automatic mode Lit when that massage POSITION AUTO light...

  • Page 9: Troubleshooting

    Troubleshooting Warranty Your Restwell massage armchair comes with a comprehensive twelve-month Symptom Cause Possible solution warranty. For warranty issues and claims please contact your Drive Medical dealer. The Noisy operation Noise occurs during use. These are normal sounds during warranty conditions are below: operation.
