VarioTherm Pumped Manifold Manual

www.variotherm.at
EEI ≤ 0,20
e980313 © VARIOTHERM HEIZSYSTEME GMBH
230V AC
50 Hz
50
2-14 heating circuits
Boiler flow: 3/4" female thread
Boiler return: 3/4" female thread
Surface heating flow: 3/4" Eurocone
Surface heating return: 3/4" Eurocone
Check valve
Main pump
Caution! Observe the required capacity (pipe diameter).
Primary pressure required!
The flow rate in the boiler circuit is adjusted using the regulating
valve when the fixed-value regulator is fully opened (
Boiler circuit
Setting the fixed value regulator
• The boiler flow temperature
flow temperature of the surface heating .
• The temperature can be continuously adjusted between 20 and 70 °C.
The scale of 1-7 on the handwheel gives the following target
temperatures (guideline):
1
20 °C
| GÜNSELSDORFERSTRASSE 3A
Pumped Manifold (PVST) [1/3]
Fixed value control station for surface heating
230V AC, 50 Hz,
provided connection cable: 3 x 0,5 mm² (max. 3 A),
Room
please note the electrical protection!
thermostat
PIANO H Immersion sleeve with
flow temperature sensor
with heat transfer paste
(Safety data sheet: www.variotherm.at)
30
20 40
°C
10 50
0 60
UPS/
Yonos Alpha2
Fixed value regulator
PARA 15/6
15-60
with remote sensor
2 3 4
30
20 40
°C
10 50
0 60
55 130 115 35 ...mm
fuel boiler, remote
)
30
20 40
°C
10 50 50
0 60
Yonos Yonos Yonos Yonos
PARA 15/6 PARA 15/6 PARA 15/6 PARA 15/6
2 3 4
30
20 40
°C
10 50 50 50
0 60
must be at least 10 K higher than the set
2 3
28 °C 37 °C
| 2544 LEOBERSDORF | AUSTRIA
with existing main pump
Temperature limiter
Factory setting 60 °C
Flushing ball valve
close when flushing
Regulating valve
Heat generator
e.g. gas, oil, solid
heating and buffer
Installation depth PVST:
125 mm
30
20 40
°C
10 50 50
0 60
Yonos Yonos Yonos Yonos
PARA 15/6 PARA 15/6 PARA 15/6 PARA 15/6
30
20 40
°C
10 50 50 50
0 60
Surface heating circuit
4 5 6
45 °C 53 °C 62 °C
| T: +43 (0) 22 56 - 648 70-0
Consumers with
presettable
flow rate
2 3 4
7
70 °C
