Anleitung/Manual
Lazy Camping – Lazy Tent
120
Minutes
2
Persons
Please read first
Thank you for choosing a Lazy Tent from Lazy Camping.
Before you begin, take a moment to familiarize yourself with these instructions and the parts included.
On page 2 you will find a list of all parts, quantities and tools needed.
Important notes
It is essential that all Lazy Camping products are properly and securely mounted and attached to your
vehicle. Improper attachment can result in an accident and cause serious bodily injury or death. You are
responsible for mounting and securing all Lazy Camping products to your vehicle. Attachments must be
inspected before use and products must be checked regularly for adjustment, wear and damage. Therefore,
you must read and understand all instructions and cautions before mounting or using Lazy Camping
products. If you do not understand all the instructions and cautions, or if you have no manual experience
and you are not thoroughly familiar with the assembly procedures, you should have the product installed
by a professional assembler or other qualified persons.
Ausführliches YouTube Video
zum
Lazy Tent – Aufbau
Advertisement
Summary of Contents for Lazy Camping Lazy Tent
- Page 1 On page 2 you will find a list of all parts, quantities and tools needed. Important notes It is essential that all Lazy Camping products are properly and securely mounted and attached to your vehicle. Improper attachment can result in an accident and cause serious bodily injury or death. You are responsible for mounting and securing all Lazy Camping products to your vehicle.
- Page 2 Materialliste Bag 1 • 4x end caps for mounting rail (+2x spare) • 18x M8 screws for mounting rail • 18x washer M8 • 18x spring washer M8 for mounting rail 18x slot nuts M8 for mounting rail (already in •...
- Page 3 Bag 4 • 6x fully threaded screws 35 mm M5 (+2 spare) • 6x lifting nuts M5 (+2 spare) 6x washer M5 (+2 spare) • • 6x spring washer M5 (+2 spare) • 4x fabric straps (spare) Bag 5 2x fully threaded screws 50 mm M8 •...
- Page 4 7x inner laths • • 2x outer laths 2x long brackets • • 1x canopy bracket • 4x short bars 2x short bars with hole • 1x telescopic ladder • • 1x ladder bag Detailed YouTube video Lazy Tent - Assembly...
- Page 5 2x Mounting rail • 1x Inner tent • 1x Outer tent 1x PVC cover • • 2x PVC cover belt • 2x Shoe bags • 4x Hard foam panel • 1x Opening rope Detailed YouTube video Lazy Tent - Assembly...
- Page 6 CONSTRUCTION Step 1 Screw the outer frame together You need: Tools 2x Outer frame 2x Allen key small M4 • • 2x Inner frame • 4x frame connection caps • 16x sleeve screw M4 • 16x washer M4 • 16x spring washer M4 •...
- Page 7 Step 2 Install the slatted frame You need: Tools • 2x outer laths, each with 2 additional holes in 8 mm open-end wrench • the front area 5s Allen wrench • • 7x inner slats For the connection outer slats: •...
- Page 8 Connect the outer frames to the outer laths in the very first hole. Before inserting the lifting nut and spring washer at the bottom, place a connecting tab between each. 1. Insert fully threaded screw 35 mm from the inside to the outside. 2.
- Page 9 Step 3 Attach the mounting rails You need: Tools 2x mounting rail 1x Allen key M8 • • 18x M8 screws for mounting rail • 18x washer M8 • 18x spring washer M8 for mounting rail • 18x slot nuts M8 for mounting rail •...
- Page 10 Step 4 Die Befestigungswinkel anbringen You need: Tools 2x mounting bracket 8 mm open-end wrench • • 4x fully threaded screw 30 mm 4 mm Allen • • 2x fully threaded screw 35 mm • 6x spring washer • 2x washer •...
- Page 11 Step 5 Connect the bracket and canopy rods You need: 2x Long stirrup bars without bend • 4x short bars without hole • 1x long canopy poles with bend • 2x short poles with hole • 1x opening rope • Now connect the 4 small rods (without hole) with the 2 straight bracket rods.
- Page 12 Place the clamping bracket between the canopy bar and the connector. Pass the fully threaded screw through the tensioning bracket-canopy bar-tensioning bracket. Stick nut Then tighten well. The Allen key locks and the open-end wrench tightens. Detailed YouTube video Lazy Tent - Assembly...
- Page 13 1. Semi-threaded screw 2. Eyelet gas spring 3. Spacer 4. Spacer 5. Canopy rod 6. Spacer 7. Stick nut Then tighten well. The Allen key locks and the open-end wrench tightens. Detailed YouTube video Lazy Tent - Assembly...
- Page 14 Inner fabric • Unfold the inner fabric and place it inside the frame. The Lazy Tent logo must be on the front left. Then connect the tabs that we attached to the outer battens in step 2 to the inner tent at all 4 corners.
- Page 15 Step 9 Connect the outer tent You need: Outer tent • First unfold the outer tent - the side with the longer piece is the front side. Connect the outer tent to the rear connecting flaps of the platform. To do this, pass the outer tent flap through the plastic opening of the already connected inner tent and outer frame flap.
- Page 16 Put in hard foam panels Place the four hard shell panels in the tent. Step 12 Fasten the Velcro Close the tent and turn it over once. Now attach the inner tent to the platform from below. Detailed YouTube video Lazy Tent - Assembly...
- Page 17 Step 13 Connect the roof tent with the roof racks You need: Notice 4x mounting bracket • The mounting rails are 80 cm apart. Therefore, 8x screws M8 45 mm you have to make sure that the free surface of •...
- Page 18 Step 15 The ladder Loosen the Velcro and place the hooks in the ladder. Then hook the telescopic ladder* between the tent and the frame and pull it down rung by rung. Step 16 End caps Clip the 4 cover caps to the 2 mounting rails Step 17 The PVC-Cover Pass the straps through the openings of the...
