Summary of Contents for Ekobom BOECO-450
- Page 1 Health is starting from the kitchen! User Instruction Combi Fridge Freezer No-Frost BOECO-450 Content 1. Safety Information Page 1~5 2. Overview Page 6 3. Installation Page 7~10 4. Daily Use Page11~17...
- Page 2 Safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features.
- Page 3 Safety information WARNING! Do not use other electrical appliances (such as ice cream makers) inside of refrigerating appliances, unless they are approved for this purpose by the manufacture. WARNING! Do not touch the light bulb if it has been on for a long period of time because it could be very hot.
- Page 4 Safety information Power cord must not be lengthened. Make sure that the power plug is not squashed or damaged by the back of the appliance. A squashed or damaged power plug may overheat and cause a fire. Make sure that you can come to the mains plug of the appliance. Do not pull the mains cable.
- Page 5 Safety information Installation Impor tant! For electrical connection carefully follow the instructions given in specific paragraphs. Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it. In that case retain packing. It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back in the compressor.
- Page 6 Safety information Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. The insulation foam contains flammable gases: the appliance shall be disposed according to the appliance regulations to obtain from your local authorities.
- Page 7 Overview Note: Above picture is for reference only. Real appliance probably is different.
- Page 8 1380mm...
- Page 9 Level doors After transportation or door balconies are loaded by food or beverage, upper two doors may not be aligned. There are 3 C type washers which are used to adjust doors. Please follow below process to level doors. 1.Before check alignment of doors, please make sure appliance stand levelly . 2.If top of upper two doors looks not in a line, please slightly lift lower door and insert a pieces of C type washer by a clip between bottom of door and middle hinge.
- Page 10 Rubber blocks There is one rubber block on each door. They function as spring to relieve impact when door closes . Please not pull the rubber blocks. If they absent from the doors, please take one from accessary bag and insert it to the hole of door. WARNING!Please keep rubber blocks far away children to avoid them are swallowed by children.
- Page 12 Daily Use Daily Use Using the Control Panel 1.1 KEY OPERATION A.Temperature Control of Fridge Compartment B.Temperature Control of Freezer Compartment C.Mode/ Locking / Unlocking 1.2 LED DISPLAY 1.Temperature of Fridge Comparment 2.Temperature of Freezer Comparment 3.ECO Mode 4.Holiday Mode 5.Super Mode 6.Locking / Unlocking 2.0 OPERATING CONDITION...
- Page 13 Daily Use Daily Use 2.1.2 The panel will be lit up by any key operation whereas the light would be out 2 minutes after the last operation. 2.1.3 Display during normal operation Temperature Display of the Fridge Compartment: Indicating the temperature of the current setting.
- Page 14 Daily Use Daily Use 4.0 ECO mode Press mode to choose ECO mode, ECO icon keeps bright after 5 sec flashing. 5°in fridge compartment and -18°in freezer compartment under eco mode, “Freezer”&“Fridge“ button in vain while eco icon will flash three times in alarm. Exit eco mode Press mode again to exit eco mode after 5 sec, entering the selected mode.
- Page 15 Daily Use First use Cleaning the interior Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm water and some neutral soap so as to remove the typical smell of a brand new product, then dry thoroughly. Important! Do not use detergents or abrasive powders, as these will damage the finish.
- Page 16 Daily Use Daily Use Hints for storage of frozen food To obtain the best performance from this appliance, you should: make sure that the commercially frozen foodstuffs were adequately stored by the retailer; be sure that frozen foodstuffs are transferred from the food store to the freezer in the shortest possible time;...
- Page 17 Daily Use Daily Use Humidity Adjustment for Crisper Zone :KHQ WKH NQRE LV SODFHG DW WKH +,*+ SRVLWLRQ WKH FULVSHU KXPLGLW\ LV KLJK ZKLFK LV VXLWDEOH IRU YHJHWDEOH :KHQ WKH NH\ LV SODFHG DW WKH /2: SRVLWLRQ KXPLGLW\ LQ WKH FULVSHU LV ORZHU ZLWK LV VXLWDEOH IRU IUXLWV Cleaning For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
- Page 18 Daily Use Daily Use Troubleshooting Caution! Before troubleshooting, disconnect the power supply. Only a qualified electrician of competent person must do the troubleshooting that is not in this manual. Important! There are some sounds during normal use (compressor, refrigerant circulation). Possible cause Solution Problem...
