In-Door Use PIR Motion Detector
(Human Body Detector)
Quick Start Guide
Please read the quick start guide carefully before you use this series product!
This quick start guide is for (including but not limited to) WP1
and DH-CE-S200 series product.
Pair
Detector
Indicator Light
Batter y Cover
Bracket
Pair
Press it for a long time (About 6 seconds) to go to the pair mode.
Indicator light
The blue light is flashing quickly when the device is in pair
mode. The light becomes off when the pair mode is complete.
The blue light flashes three times when there is an alarm.
The blue light is on for three seconds and then turns off when
you are inserting the batter y.
The red light flashes slowly, it is to alert you to change the
batteries.
Batter y cover
Press it to install/replace three 7# batteries.
Bracket
Use bracket to install on the wall or in the ceiling.
You can use this product to work with the LeBox, and then go to the
client to set the mode to detect the human body movement.
Quick Pair
Please follow the steps listed below to pair the human body detector
and the LeBox up.
Step 1
Open the software management interface and then select
Add device button.
Step 2
Press the Pair button for about 6 seconds; you can go to
the pair mode. Now you can see the blue indicator light
becomes flashing quickly. The light becomes off after the
pair mode is complete.
You can view the pair is successful on the LeBox and the
device is added to the human body detector categor y.
