USER MANUAL
802.11n, 2.4G 1T1R Wireless LAN USB Module
WN4608L
Realtek RTL8188ETV
Networking B.U.
Lite-on Technology Corporation
4F, No. 90, Chien I Rd.,
Chung Ho, New Taipei City 235, Taiwan, R.O.C.
Phone: +886-2-2222-6181
Fax: +886-2-2221-5288
Contact: Product Marketing
Mr. ML Wu #8266
E-mail:
Customer Approval:
Version 1.2
ml.wu@liteon.com
Page 1/6
(Signature)
(Title)
(Company)
(Date)
Advertisement
Table of Contents
Summary of Contents for LiteOn WN4608L
- Page 1 USER MANUAL 802.11n, 2.4G 1T1R Wireless LAN USB Module WN4608L Realtek RTL8188ETV Version 1.2 Networking B.U. Lite-on Technology Corporation 4F, No. 90, Chien I Rd., Chung Ho, New Taipei City 235, Taiwan, R.O.C. Phone: +886-2-2222-6181 Fax: +886-2-2221-5288 Contact: Product Marketing Mr.
- Page 2 RODUCT EATURES Wi-Fi Feature Operate at ISM frequency Band (2.4GHz) IEEE Standards Support, 802.11b, 802.11g and 802.11n CMOS MAC, Baseband PHY, and RF in a single chip for IEEE 802.11b/g/n compatible WLAN Complies with USB Specification 2.0, support Full-speed(12Mbps) and High-Speed(480Mbps) ...
- Page 3 RODUCT PECIFICATIONS HIPSET Realtek RTL8188ETV UNCTIONAL PECIFICATIONS Wi-Fi Function Standard IEEE802.11b; IEEE 802.11g; IEEE 802.11n Bus Interface USB 2.0 802.11b: 11, 5.5, 2, 1 Mbps 802.11g: Data Rate 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n: MCS 0 to 7 for HT20MHz MCS 0 to 7 for HT40MHz Media Access Control CSMA/CA with ACK...
- Page 4 -68 dBm@MCS7 40MHz -65dBm@MCS7 WEP 64&128 bit, WPA, WPA-PSK, WPA2, WPA2-PSK, Security WPS, IEEE 802.1X, IEEE 802.11i Operating Voltage 3.3 V ±5% I/O supply voltage OS Supported Microsoft Windows Win7/Win8; Linux based TX Mode: Power Consumption 234 mA Test Condition: RX Mode: - Operate at HT40 162 mA...
- Page 5 FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 6 LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX FCC ID: MDZ-WN4608L The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module.
