Forest garden DAMSON PLAYHOUSE Instruction & Reference Manual

DAMSON PLAYHOUSE
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
- Most buildings are pre-treated with a factory base coat for protection
during storage and transit. We recommend that you treat your new
building as soon as possible after assembly using a wood preservative
treatment. Apply in accordance with the manufacturers instructions.
- Timber is a natural material. It will shrink and swell as a result of
varying moisture content.
- Please keep all plastic bags and small parts away from children
- This product must be built on a solid level base and at least two
metres away from any structure or obstruction.

Warnings

-This product is for outdoor use only.
-This product is intended for use by children of up to age 10 years.
-Only for domestic use
0333 7777 089
Technical Help line: 8.30 am and 5.00 pm Monday to
Friday.
In line with your statutory rights, please check all parts prior to
assembly, as assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled to. If the
product is not constructed in accordance with the instructions, or is
altered in anyway (e.g. painted), the manufacturer cannot be held liable
for any resulting damage
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products
to give protection against wood destroying insects & wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)),
Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting
treated or untreated wood. Dispose of off-cuts responsibly – do not burn.
Fixing Pack (PH8FPV2)
46
25mm Screw 25mm Screw (black)
50mm Screw
20
30mm Screw
32
Panel Pins
90
FELT NAIL
PH8 Parts list:
E
Not to Scale
(Door) Qty 1
14
1
32
L
Magnetic
Catch and Plate
N
2
Hinge
REQUIRED TOOLS: (NOT SUPPLIED)
TAPE MEASURE
SPIRIT LEVEL
POZI DRIVE SCREWDRIVER
Warning. Only for domestic use
A B
PH1PE PH2DPV2
(Plain End) Qty 2 (Door Panel) Qty 1
F
18386908
PH1DR
(Roof sheet) Qty 2
I
J
SBB80120875PAII45DT
(Barge Board) Qty 4
28281838CRCT (Batten 1832mm) Qty 2
M
28281758CRCT (Batten 1758mm) Qty 1
40120586PAIIDT
(Strip 586mm ) Qty 4
DRILL
Important :
Assembly of this
product requires
MUST PRE DRILL
a minimum of two
adults only
.
C
PH2PP
(Large Plain Panel) Qty1
G
(Door Handle 100mm) Qty 1
PW480250
(Window) Qty 4
40121024PARDTR
(Corner Strip 1024mm) Qty 4
P
O
40120530PAIIDT
(Strip 530mm ) Qty 4
Issue 0414
PH8
Instruction Reference
EN71 COMPLIANT
Slipping, Tripping
& Falling
D
PH8FL
(Floor) Qty1
H
28280100CRCTDTR
85052
Felt Qty 1
K
15120250PARDTR
(Glazing Strip) Qty 16
28280694CRCTA1
(Batten 694mm ) Qty 2
