HomeAware Sonic Alert HA360WRB Quick Reference Manual

Complete Home Alerting Solution
1
Setting Up Your HomeAware™
1. Remove all contents of the box.
– HomeAware™ - Main Unit
– HomeAware Security Alert
– HomeAware Bes Shaker
– NOAA Weather Radio
– 3.5mm Connection Cable
2.
– P lug the power supply into back of
the Main unit, 7.5V 2A DC IN.
3. Plug Main unit power supply into a
120V outlet.
Plug Vibrator / Bed Shaker into the
4.
vibrator outlet on the back of the
Main unit. (Optional).
2

Setting Time of Day

1. Press the Time Set button. Blinking red dots
will show on the display.
2. Press the Hour and Minutes buttons up or
down to set desired time. When setting the
time make sure the PM indicator light reflects
the correct time.
3. Press the Enter button to complete.
For addtional information refer to your
HA360M2.1 User Guide.
3

Connecting the HA360SA2.1 to your NOAA Weather Radio

1. Remove the 3.5mm Double-Ended Connection Cable
2. Plug the 3.5mm cable into the External Alert outlet on the back of your NOAA Weather Radio.
3. Plug the other end of your 3.5mm cable into the outlet on side of the HA360SA Security Alert.
For addtional information refer to your HA360SA and NOAA Weather User Guides.
4

HA360SA2.1 Switch Locations and Positions

1. There are three switch positions on the back of the HA360SA
– N / closed
– N / open
– Door chime
2. Using the HA360SA with the NOAA Weather Radio the switch.
should be in the N / open (Center location).
For addtional information refer to your HA360SA2.1 and NOAA
Weather User Guides.
HA360WRB - Quick Reference
7.5V 2A
DC IN
120V Outlet
EXT.
7.5V 2A
BATT.
DC IN
LAMP
USB CHARGE 5V
SW.
PM Indicator
Main
PM
A1
A2
Guide
VIBRATOR
TEL. CELL PHONE
TEL. LINE DETECTOR
Time Set Alarm Off Set Up
AL.1 Set Volume Tone
Enter
AL.2 Set Hour Minute Back
SNOOZE
VIBRATOR/
BED SHAKER
