This document includes both installation and user guides of the 4E-CMP, the push-button microphone station for the Compact 500 Voice Evacuation System. It explains how the 4E-CMP should be installed and configured. Installation instructions are addressed to trained technical personnel, such as installers, service technicians and commissioning engineers.
2651BC Berkel & Rodenrijs Author: 4E-CMP installation and user guide Table of Contents 1. What is the 4E-CMP? ................................3 2. Where do I start? ..................................3 3. Configuration settings ................................4 4. Hardware installation and settings ............................ 5 L-Net ....................................5 4.1.1.
4E-CMP installation and user guide Thank you for choosing 4EVAC as your Voice Evacuation System solution. 4EVAC Compact 500 is an all-in-one Voice Evacuation System box. The box contains a completely integrated Voice Evacuation System, capable of both standalone and network operation. 4EVAC Compact 500 is certified in accordance with EN54-16 and EN54-4, which are harmonized standards under the Construction Products Regulation, mandatory in the European Union.
4E-CMP installation and user guide 3. Configuration settings Settings for the 4E-CMP are included in the configuration file located on the micro SD memory card installed in the Compact 500 main unit. This configuration file includes user-defined settings, such as:...
4. Hardware installation and settings L-Net 4E-CMP is a remote station connected to the L-Net port of the C500 main unit. Multiple 4E-CMP stations may be used in the same L-Net, with the following limitations: A maximum of 8 stations per L-Net port...
4E-CMP installation and user guide 4.1.2. Network cabling 4EVAC network features a full duplex RS-422 data link and 24V DC power to remote devices. If you’re building a distributed system using the 4EVAC network, you should make physical links between devices using the right cables.
Plug-in the L-Net cable connecting the station with the C500 main unit. Observe the boot sequence which should see the unit automatically entering normal operating mode afterwards. Assemble the back plate (and optionally the rubber feet). 4E-CMP bottom view: Device ID setting Page 7 of 11...
Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-CMP installation and user guide 5. Front Panel 4E-CMP button panel LED indicators 5.1.1. Zone indicators –blue LED Zone busy / zone selection LED. Continuous: indicates that the zone is manually selected via...
Zone labels The front panel of the 4E-CMP has an opening dedicated for a sheet with zone labels. The text sheet, 120 x 50 mm in size, is meant to be inserted (slide-in) via the opening in the upper part of the panel, all the way down the available space.
Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-CMP installation and user guide 6. Technical specifications 4E-CMP Number of zones max. 6 zones (global network access) Controls and indications 6 x configurable zone selection button, zone SELECT/BUSY LED indicators...
