Jackeroo 42120834 Instruction Manual

Jackeroo 12 Person Cabin Tent
Locate all the poles and assemble them as
shown below.
Pole A(2M)
Pole B(1.9M)
Pole C(2.4M)
Pole D(3.94M)
Pole E(2.55M)
Pole F(1.8M)
(Keycode: 42120834)
Inner tent body
1
2
Flysheet
3
Room divider sheet
4
Steel pole A(2M)
5
Steel pole B(1.9M)
6
Steel pole C(2.4M)
7 Fiberglass pole D
Fiberglass pole E with
8
grey marking (2.55M)
9 Steel awning pole F(1.8M)
Plastic three ways knuckle
10
G with red marking
(attached to inner)
Plastic three ways knuckle
11 H with red marking
(attached to inner)
Plastic two ways knuckle I
12
(attached to inner)
13 Guy ropes
14
Pegs
Please read all instructions carefully and make sure you have
all parts before starting to assemble
Spread out the inner tent body. Insert the pole D &E
through the pole sleeve on the inner tent body, insert
all the pole end into the knuckle. Match the color
marking. Insert the pole C into knuckle and attach the
hooks to each pole.
X4
X2
X2
(3.94M) X2
X1
X2
X2
X2
X2
X8
X18
D
E
D
C
C
