PROWatt 800/1000/1500/1750
Owner's Guide Addendum
Front Panel (AC End)
This addendum is issued to expand the Ground Fault Circuit Interrupter (GFCI)
outlet features of the PROWatt series products.
The addendum affects the following PROWatt products:
•
PROWatt 800 Owner's Guide (part no. 440-0159 Rev 5)
•
PROWatt 1000 Owner's Guide (part no. 445-0116-01-01)
•
PROWatt 1500 Owner's Guide (part no. 445-0160 Rev 5)
•
PROWatt 1750 Owner's Guide (part no. 445-0117-98-01)
This section affects the description of the AC Outlet with Ground Fault Circuit
Interrupter (GFCI) of all the above mentioned PROWatt products.
➃
ON
OFF
➆
➀
➁
Figure 1 AC Outlet with GFCI (PROWatt 1750 model shown)
Feature
Description
➅
AC Outlet. This is a Ground Fault Circuit Interrupter (GFCI) outlet,
equipped with an LED indicator light. The LED comes on when AC power
is interrupted due to a ground fault or an end of life (for the GFCI) fault.
See
➅
➂
➄
below.
Addendum
PROWatt Series
976-0159-01-01 Rev A
LED
➆
