This reference guide summarizes all of P
highly recommend that you review this booklet before using your unit.
Summary
Configuration switches, page 1.
Dialing instructions, pages 2-3.
Distinctive ring patterns, pages 3-4.
Caller-ID operation, pages 4-5.
Special Features, page 6.
Message waiting support, page 6.
Configuration Switch Settings
There are several user configured features that can be used to personalize P
application. To change the unit's features, easy-to-set switches, labeled J6, J7, J8, and J9, are
available at the rear panel. Normally all the various features are enabled, as provided by all the
switches set in their "UP" position. Please see Table 1 for the various settings.
TABLE 1, Configuration Settings
Switch
Switch "UP"
J6
Enable Recall Dial Tone Disable Recall Dial Tone
Enable "L" Features
J7
Enable Distinctive Ring
J8
Name and Number
Delivery
J9
Enable Caller-ID
Jumper Settings
Two system feature settings are available as plug-in "jumpers." These jumpers are located inside the
unit and are labeled J1 and J10. You can access the jumpers by removing the two screws on the
bottom of the enclosure (unplug power first!), then slide the top cover off. See Table 2 for the various
jumper settings.
Party-Line Quick Reference
@Qbdi <Y^U
Digital Products Company (USA)
Tel 916-985-7219, Fax 916-985-8460
e-mail: info@digitalproductsco.com
http://www.digitalproductsco.com
Quick Reference Guide
Version 2 Software Option
© 1998-2004
-L
ARTY
INE
Switch "DOWN"
Disable "L" Features
Disable Distinctive Ring
Number Only Delivery
Disable Caller-ID
Page 1
™
's features, including the latest additions. We
-L
for your
ARTY
INE
©
Jan 2004
Advertisement
Table of Contents
Related Manuals for Digital Products Party-line
Summary of Contents for Digital Products Party-line
- Page 1 @Qbdi <Y^U ™ Digital Products Company (USA) Tel 916-985-7219, Fax 916-985-8460 e-mail: info@digitalproductsco.com http://www.digitalproductsco.com Quick Reference Guide Version 2 Software Option © 1998-2004 This reference guide summarizes all of P ’s features, including the latest additions. We ARTY highly recommend that you review this booklet before using your unit.
- Page 2 Dial 985-7211 and you will ring station one using the “long-long” distinctive ring pattern. Refer to Table 3 for the Extension Number Assignments and Table 4 for the Ring Patterns. © Party-Line Quick Reference Page 2 Jan 2004...
- Page 3 You should consult Table 1 for the Distinctive Ring configuration setting (jumper J7). You can even override the Distinctive Ring feature on a per-call basis by using the Z62 feature described on page 6. © Party-Line Quick Reference Page 3 Jan 2004...
- Page 4 “0” or “1”. See Table 4 for the six names that are used when calls are from the corresponding station. © Party-Line Quick Reference Page 4 Jan 2004...
- Page 5 Whenever you begin a new dial sequence with “Z”, followed by two digits (00-99), you will hear three short beeps followed by dial tone. This tone sequence is called Recall Dial Tone and is similar to the beeps heard on some phone systems during special dialing modes. © Party-Line Quick Reference Page 5 Jan 2004...
- Page 6 CLASS/FSK central office areas. Some agencies call this Visual Message Waiting Indication (VMWI) . Party-Line sends the BELLCORE CLASS/FSK specified single data message formatted VMWI signal. The stutter dial tone method is also provided to ensure compatibility with older indicator systems.
- Page 7 “Z91#10”. This example used the quick dial number format where the #10 indicates station one *OMOZGR6XUJ[IZY &RPSDQ\ Folsom, CA USA Tel 916-985-7219, Fax 916-985-8460 e-mail: info@digitalproductsco.com http://www.digitalproductsco.com © Party-Line Quick Reference Page 7 Jan 2004...
- Page 8 Another extraordinary product from Digital Products Company. © 1998-2002, All rights reserved.
