Star Warning Systems STARVISION II VL22 Quick Start Manual

Led visor light

MODEL VL22 LED VISOR LIGHT

30 Tilt-Activated Flash Patterns – Lightweight – Polycarbonate

The VL22 uses state-of-the-art Light Emitting Diode (LED) technology. This

warning light is comprised of ultra-high intensity LEDs that are operated by a micro-

controller to efficiently produce light output with lifetimes up to 100,000 hours.

IMPORTANT: Please read all of the following instructions before installing your new Model VL22

STARVISION II™ LED Visor Light .

CAUTION: Please be sure to check that your cigarette plug outlet is properly fused. Testing the

light before this fuse is properly installed will void the warranty on the light.

WARNING!!!! Care should be taken when positioning this warning light on the visor so that the light

and/or cord does not interfere with the proper operation of the driver-side or passenger- side

airbag! Failure to heed this warning may result in serious or fatal injury.

The STARVISION II™ visor light is designed to be mounted on the inside of

your vehicle. It is not intended for exterior applications.

It is the sole responsibility of the owner to ensure the warning light is

secure. Check your light every time you enter the vehicle to ensure that it

is mounted securely. Star Headlight and Lantern Co. assumes no

responsibility for the secure mounting of this light.

STARVISION II

Voltage : 10-16VDC

Current Draw : Approx. 1.5 Amps

™

PLITSTR284 REV. D

3/29/05

Table of Contents

Need help?

Do you have a question about the STARVISION II VL22 and is the answer not in the manual?

Page 1 STARVISION II ™ MODEL VL22 LED VISOR LIGHT 30 Tilt-Activated Flash Patterns – Lightweight – Polycarbonate Voltage : 10-16VDC Current Draw : Approx. 1.5 Amps The VL22 uses state-of-the-art Light Emitting Diode (LED) technology. This warning light is comprised of ultra-high intensity LEDs that are operated by a micro- controller to efficiently produce light output with lifetimes up to 100,000 hours.
Page 2 Mounting 1. The STARVISION II™ Visor Light comes equipped with two Velcro straps for standard visor mounting. Please read all of the following instructions before installing your new STARVISION II™ Visor Light . 2. Place the vehicle’s sun visor in the “down” position.
Page 3 Operation When in the “ON” mode, the STARVISION II™ LED Visor Light is designed with a tilt sensor to automatically turn the light “ON” when the visor is flipped down and turn the light “OFF” when the visor is pushed back up. This light was also designed with provisions to de-activate the tilt switch.
Page 4 The VL22 uses state-of-the-art Light Emitting Diode (LED) technology. This warning light is comprised of ultra-high intensity LEDs that are operated by a micro-controller to efficiently produce light output with lifetimes up to 100,000 hours. Under normal circumstances, you will not need to replace any lights in this warning light. PARTS LIST Circuit (Red/Blue) S8070-228-1...
