- Page 1 LUNE ™ ASSEMBLY INSTRUCTION Design: Jaime Hayon, 2017...
- Page 2 When a electric screwdriver is used, adjust the t • Lift the cardboard tube of, when the items are orque equivalent to 1/3 strength, to prevent the screw unpacked. The elements do not need to be lifted is turned over out of the package LUNE ASSEMBLY INSTRUCTION ™...
-
Page 3: Assembly Sequence
Please note the extruding screw when handling the elements Align the empty cardboard boxes to support the modules while assembling. ASSEMBLY SEQUENCE When a sofa consists of more than two modules, use the additional box for support while assembling. LUNE ASSEMBLY INSTRUCTION ™... - Page 4 The bracket are self supporting when positioned correct • Tighten the nut well (approx. 5N) • Perform step 3 + 4 with the remaining modules, until the complete sofa is assembled Make sure the bracket are aligned! LUNE ASSEMBLY INSTRUCTION ™...
- Page 5 Avoid separating the front after the assembly brackets are removed. LEG POSITION FOR DIFFERENT CONFIGURATIONS Configurations with three straight modules between end modules have legs positioned in the middle of the center module. This module is marked “Center module” on the carton outside. LUNE ASSEMBLY INSTRUCTION ™...
