OU Lighting CREE LEDs EHL6S11K Quick Start Manual

Premium 144-watt LED Spotlight with
Wall Mount Bracket
Model: EHL6S11K

Features:

•
50,000 hours of maintenance-free operation to L
•
Non-dimmable
•
Die-cast aluminum housing and lens frame
•
Dark bronze polyester powder-coat finish
•
Tempered glass lens, thermal shock and impact resistant
•
2" Adjustable slip fitter included (for 2-3/8" O.D. Pipe)
•
Precise optical reflector
•
Heat dissipating fins
•
High-powered LED arrays
•
Suitable for ground mounting, uplighting & downlighting
The wall mount bracket with 2-3/8" tenon attaches an OU Lighting's floodlight to almost any surface: wall,
roof, wood pole, or the ground. Provides wiring access and a built-in 2-3/8" O.D. tenon to mount a fixture
with our adjustable slip fitter (E-ACS not included). Suggested 3/8" diameter bolts for mounting. Mounting
holes are spaced 3-1/4" apart.
CAUTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Turn off power supply to avoid the risk of electrical shock.
2. This product must be wired in accordance with the National Electrical Code and applicable local codes and ordinances. Proper grounding is
required to ensure personal safety. A qualified electrician should do all work.
3. Suitable for mounting within 4 feet of the ground.
4. For supply wire temperature rating, refer to fixture label.

Package Contents:

•
One (1) EHL6S11K LED Spotlight
•
One (1) EACWM2 Wall Mount Bracket
•
One (1) User Manual

Applications:

Building facades, displays, uplighting and signs. Also effective as security lighting for storage areas and commercial sites.
Typical Mounting Height: 12 to 25 feet
www.oulighting.com
Copyright © 2014. All rights reserved.
at 15°C
70
•
RoHS compliant
•
UL Listed for wet locations
•
Cree® LEDs inside
•
3-year warranty
•
Universal voltage (120V ~ 277V)
Outdoor
R201406-V12
