Summary of Contents for SMTV 55LI0521-1

  • Page 1 Read this manual carefully and retain for future reference...

  • Page 2: Table Of Contents

    CONTENTS 1. Safety instructions ............................3 2. Accessories..............................5 3. Controls and connections ..........................5 3.1 Front view/side view ......................... 5 3.2 Rear View............................6 3.3 Remote Control ..........................7 4. System Connections ..........................10 4.1 Connecting to Power Supply......................10 4.2 Connection to External AV Signal Source..................

  • Page 3: Safety Instructions

    1. Safety instructions Welcome Congratulations! You now own one of the most state of the art and technologically advanced high definition Television products available. In order to make set-up as easy as possible, we would like to familiarize you with the features and functions of this special product. Please read this user s manual carefully and thoroughly and keep in a safe place for future reference.
  • Page 4 Important Safety Precautions Always be careful when using your television. To reduce the risk of fire, electrical shocks, and other injuries, keep these safety precautions in mind when installing, using, and maintaining your Television. Read these instructions and keep them in a safe place. Heed all warnings.

  • Page 5: Accessories

    2. Accessories Batteries AAAX2 Remote Control User s Manual 3. Controls and connections 3.1 Front view...

  • Page 6: Rear View

    3.2 Rear View Connecting for HDMI signal. Connect to the VGA output jack on a personal computer. Connect to the audio output jack on a personal computer. Connecting for AV signal input in composite mode.

  • Page 7: Remote Control

    3.3 Remote Control 1. POWER button Press to enter or exit the standby mode. 2. Mute button Press to select enter the source selecting menu, press the direction buttons or press the MUTE button repeatedly to select desired mode and press the ENTER button to enter the selected mode.
  • Page 8 17.HOLD Display the selected favorite up programmers. HOLD( Teletext Mode) Hold on or off for current page display. 18.MIX Display the selected favorite programmers. Mix( Teletextmode) TV and TXT pictures are mixed together on a transparent background. 19.REVEAL Display the selected favorite down programmers. 20.CANCEL Press to cancel what you are doing.
  • Page 9 Playing backward fast. 33. REC Hot key to retained. 34. USB Hot key to retained. Playing forward fast. Record Button. Preparation of Remote Control Under normal use the battery will last for six months. Place the remote control on an even Take out battery when the remote is surface and insert the supplied batteries not in use for a long time.

  • Page 10: System Connections

    The operating distance may vary depending to the brightness around. Do not point bright lights directly at the remote control sensor. Do not place objects between the remote control unit and the remote control sensor. Do not use this remote control unit while simultaneously operating the remote control unit of any other equipment.

  • Page 11: Connection To External Av Signal Source

    4.2 Connection to External AV Signal Source Use the audio and video cable to connect the input jacks on the rear panel of the unit to the external AV signal source. Connect the unit and the external AV signal source to the respective jacks with the S-Video cable.

  • Page 12: Connecting To External Av Signal Source (Hdmi)

    SOURCE then direction buttons to select YPbPr mode, and then press the ENTER button to confirm. 4.4 Connecting to External AV Signal Source (HDMI) Follow the figure below to connect an HDMI signal source to the HDMI jack on the rear panel of the unit.

  • Page 13: Connecting To Tv-Signal Input

    After connection, turn on the power of the unit and the external AV signal source and use the SOURCE and the direction buttons to select VGA mode, and then press the ENTER button to confirm. 4.6 Connecting to TV-Signal Input Connect the TV signal cable (the antenna cable, for example) to the antenna input jack on the back of the unit so that you can receive television programmers.

  • Page 14: Tv Operation And System Setup

    5. TV OPERATION AND SYSTEM SETUP SELECT INPUT SOURCE Press SOURCE button to display the input source list; select the input source you want to watch; Press ENTER button to enter the input source;...
  • Page 15 Press MENU button to display the MAIN OSD MENU; Press ENTER back to the previous menu. ENTER to select in the sub menu; You can press MENU button to save and return back to the previous menu, and press EXIT button to exit the entire menu. Press INFO button on the remote control to display program information.

  • Page 16: Picture Menu

    5.1 Picture Menu The picture is for a reference only; the actual item is the standard. Press TV MENU button to display the main menu. Picture in the main menu, and then press ENTER button to enter. then press ENTER ENTER button to select the sub menu.

  • Page 17: Sound Menu

    TIPS: You can press P-MODE button on the remoter control again and again to change the picture mode directly. 5.1.2 Aspect Ratio ENTER button to adjust. Then press MENU button to return back the previous menu directly. 5.1.3 Colour Temperature Colour Temperature, then press ENTER button to enter and 5.1.4 DNR Press...
  • Page 18 5.2.1 Sound mode Sound mode, and then press ENTER button to enter. And then You can change the value of bass and treble, Balance and EQ, when the sound is in User mode. TIPS: You can press S-MODE button on the remote control to change the Sound Mode directly.

  • Page 19: Timer Menu

    to select. (Available SPDIF mode: RAW, PCM, OFF) Then press ENTER MENU button to return back the previous menu directly. 5.3 Timer Menu 5.3.1 OSD Timer 5.3.2 Sleep Timer 5.3.3 Auto Power Down 5.4 System lock 5.4.1 System Lock 5.4.2 Source lock 5.4.3 Channel lock 5.4.4 Program Restrictions...

  • Page 20: Setting Menu

    5.4.5 Change PIN 5.5 Setting Menu The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. SETTING in the main menu, and then press ENTER button to enter. SETTING menu, and then press ENTER button to enter.

  • Page 21: Cec

    5.5.1 Menu Language to select Menu Language 5.5.2 Location Location 5.5.3 Power Default Source Power Default Source On or Off. 5.5.4 Reset TV Reset TV, and then press ENTER button to enter 5.6 CEC 5.6.1 HDMI CEC Setup 5.6.2 Device Auto Power Off 5.6.3 TV Auto power on 5.6.4 CEC device list 5.6.5 Amplifier Support ARC...

  • Page 22: Channer Menu

    5.7 Channel Menu The picture is for a reference only; the actual item is the standard. Press MENU button to display the main menu. Setup in the main menu, then press ENTER to enter. Setup menu, then press ENTER 3. After finishing your adjustment, press MENU button to save and return back to the previous menu and press EXIT button to exit the entire menu.
  • Page 23 5.7.3 Country or Region(Germany) Country and Region, and then press ENTER button to play the channel selected. The menu will appear as follows: 5.7.4 Auto Tuning Auto Search, and then press ENTER button to play the channel selected. The menu will appear as follows:...
  • Page 24 5.7.5 Manual Tuning Manual Tuning, and then press ENTER button to play the channel selected. The menu will appear as follows: 5.7.6 Record menu Press Record menu, and then press ENTER button to play the channel selected. The menu will appear as follows:...
  • Page 25 5.7.7 Subtitle Language Subtitle Language, and then press ENTER button to play the channel selected. The menu will appear as follows:...
  • Page 26 5.7.8 Multi Audio Multi Audio, and then press ENTER button to play the channel selected. The menu will appear as follows:...

  • Page 27: Quick Menu

    5.7.9 DTV Setting DTV Setting, and then press ENTER button to play the channel selected. The menu will appear as follows: 5.8 Quick Menu...

  • Page 28: Home

    6. Home 6.1 Apps The picture is for a reference only; the actual item is the standard. APPS in the Source Menu, and then press ENTER enter. you can button to select Tv Store to download apps what you want, As the figure shows.
  • Page 29 you can also select Browser to search the internet, As the figure shows.

  • Page 30: Media Operation

    6.2 TV The picture is for a reference only; the actual item is the standard. TV in the Source Menu, and then press ENTER 6.3 MEDIA OPERATION The picture is for a reference only; the actual item is the standard. Note: Before operation MEDIA menu, Plug in USB device or memory card, then press SOURCE button to set the Source to Media.

  • Page 31: Photo

    6.3.1 Photo The picture is for a reference only; the actual item is the standard. Music in the main menu, and then press ENTER button to enter. Press EXIT button to return back to the previous menu.

  • Page 32: Music

    You can see the information of the current playing photo after press INFO button, then press Notes: Other menu and description are the same as that for Movie menu. 6.3.2 Music The picture is for a reference only; the actual item is the standard. Music in the main menu, and then press ENTER button to enter.
  • Page 33 You can see the information of the current playing sonny at the left of the menu.

  • Page 34: Video

    6.3.3 Video The picture is for a reference only; the actual item is the standard. Video in the main menu, then press ENTER button to enter. Press EXIT button to return back to the previous menu. Press ENTER button to select the sub folder.

  • Page 35: Applicatopns

    Press You can see the information of the current playing media at the first flew second or after press INFO button. 6.3.4 Applications The picture is for a reference only; the actual item is the standard. Video in the main menu, then press ENTER button to enter. Press EXIT button to return back to the previous menu.

  • Page 36: Setting

    6.4 Setting The picture is for a reference only; the actual item is the standard. Setting in the Source Menu, and then press ENTER enter. 6.4.1 Network Setting -Fi. As the figure shows.
  • Page 37 6.4.2 Time Setting 6.4.3 Common...
  • Page 38 As the figure shows. As the figure shows.
  • Page 39 wallpapers that you can know these pictures. As the figure shows. downloaded and this feature you also can unload the app. As the figure shows.
  • Page 40 As the figure shows. As the figure shows.

  • Page 41: Troubleshooting

    As the figure shows. 7. Troubleshooting Carry out the problem-solving measures described in the following section before contacting customer support. Turn off the device immediately as soon as you suspect a malfunction and unplug the power plug. Do not attempt to repair the device yourself.
  • Page 42 SYMPTOM CHECK ITEM LCD screen stays Make sure the unit is turned on and the connections are correct. Dark. Make sure the power adapter is correctly connected. Make sure the system connection is correct. There is no sound Mack sure the power of speaker is turned on. Check if the connections with the external AV signal source are correct.
  • Page 43 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
