E.NEXT E.CONTROL.T08M User Manual

EN
1. Application
Electronic timer e.control.t08m (hereinafter referred to as timer) is used for realization of time functions in the control systems and automati-
on. It operates according to the set time schedule planned by the user.
The timer meets requirements of EN 60730-1, EN 60730-2-7.
2. Technical data
Parameter name
Supply terminals
Rated voltage, V
Power consumption, W
Supply voltage tolerance, %
Number of channels
Number of programs
Program
Operation modes
Summer/winter times
Time tolerance, °C
Power reserve, years
Data readout
Number of contacts
Current of contacts, A (for AC-1)
Switching capacity, VA (for AC-1)
Mechanical life
Electrical life
Rated insulation voltage, V
Protection degree
Pollution degree
Altitude, m
Ambient temperature, °C
Permissible relative humidity, %
Storage temperature, °C
Wire size, mm
2
Tightening torque, Nm
Dimensions, mm
The product must be operated under the following environmental conditions:
• non-explosive;
• does not contain corrosive gases and vapors in concentrations destroying metals and insulation;
• not rich conductive dust and vapors;
• lack of direct exposure to ultraviolet radiation;
• should not be significant shock or vibration.
Transportation and storage are only permitted in the original packaging.
3. Wiring diagram
See Pic. 1.
4. Installation and operating
• The timer is installed in a plastic or metal box on a standard DIN-rail width 35 mm with latches having two fixed positions.
• Connect the power supply: L (+) to terminal A1, N (-) to terminal A2. Output normally open timer contact (terminal 18 – NO, 16 - NC 15 - com-
mon) is connected to the phase conductor breaking load power or break the conductor actuator power switching device, such as a contactor coil.
First settings
See Pic. 4.
At the first inclusion or reset, timer can be setting with buttons «▲▼» and «OK».
Main menu
See Pic. 5.
1 Press «MENU» key to enter main menu.
2 With «▲▼» buttons select the desired item.
If there is no activity for 1 minute, the timer will automatically exit from the menu.
Time setting
See Pic. 6.
1 Select «DATE» and press «OK» key.
2 Select adequate hour with «▲▼» keys and press «OK» key.
3 Select adequate minute with «▲▼» keys and press «OK» key.
4 Exit from the setting by pressing «MENU» key.
Date setting
See Pic. 7.
1 Select «DATE» and press «OK» key.
2 Select adequate year with «▲▼» keys and press «OK» key.
3 Select adequate month with «▲▼» keys and press «OK» key.
4 Select adequate day with «▲▼» keys and press «OK» key.
5 Exit from the setting by pressing «MENU» key.
Electronic timer e.control.t08m
User's guide and manual operation
Value
A1-A2
AC/DC 24-264
1
±10
single channel
80
weekly program, daily program
manual, automatic, holiday
off, automatic changes
<1 s/day at 25
10
LCD display
1 C/O
16
4 000
10
6
10
5
250
IP20
3
2 000
-20...+55
<50 (40 °C, without condensation)
-30...+70
1...4
0,5
90×36×64
Table 1
