QUICK HITCH
PART # 25-005, CAT 1 QUICK HITCH
PART # 25-010, CAT 2 QUICK HITCH
PART # 25-019, CAT 2HD QUICK HITCH
PART # 25-020, CAT 3 QUICK HITCH
PART # 25-021, CAT 3 NARROW QUICK HITCH
PART # 25-022, CAT 2/3 QUICK HITCH
Operation Manual
This safety alert symbol identifies important safety
messages in this manual. Failure to follow this important
safety information may result in serious injury or death.
29-001
Advertisement
Table of Contents
Summary of Contents for AGKNX 25-005
- Page 1 QUICK HITCH PART # 25-005, CAT 1 QUICK HITCH PART # 25-010, CAT 2 QUICK HITCH PART # 25-019, CAT 2HD QUICK HITCH PART # 25-020, CAT 3 QUICK HITCH PART # 25-021, CAT 3 NARROW QUICK HITCH PART # 25-022, CAT 2/3 QUICK HITCH...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Intended Use ..............4 Personal Protective Equipment ..........4 General Safety ..............5 Assembly Instructions ............6 Operation Instructions ............8 Removal Instructions ............10 Maintenance ..............11 Parts List CAT 1 Quick Hitch ..........12 Parts List CAT 2, 2HD, 3, 3N, 2/3 Quick Hitch ....13 Warranty &... -
Page 4: Intended Use
Do not operate if you have doubts or questions concerning safe operation. Call our customer service department at 303-278-0664,or email at customerservice@agknx.com if you have any questions or concerns about the safe operation of this equipment. -
Page 5: General Safety
IMPORTANT SAFETY INFORMATION GENERAL SAFETY Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. Read the Operation Manual before operation. ● Do not permit children to operate this equipment at any time. Do not permit others that have not read and understood the complete Operation Manual to operate this equipment. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS INSTRUCTIONS TO ATTACH THE 3-PT OF THE TRACTOR TO THE QUICK HITCH STEP 1: Lower the tractor lift arms. Place the tractor lift arms within the slot of the quick hitch and align the holes. The model CAT 2/3 has two slots to connect the tractor a-arms. The inside slot is for CAT 2 tractors and the outside slot is for CAT 3 tractors. - Page 7 ASSEMBLY INSTRUCTIONS STEP 4: Connect the top link B with the top link pin and lynch pin. C INSTRUCTIONS TO ATTACH THE IMPLEMENT TO THE QUICK HITCH STEP 1: Bushings might be required to connect your implement to the quick hitch. Bushings are required if the diameter of the implements lower hitch pin is smaller than the lower hooks of the quick hitch.
-
Page 8: Operation Instructions
OPERATING INSTRUCTIONS STEP 2: Move the tractor to position the quick hitch's lower hooks below the implements bushings or lower hitch pin. Position the hook of the quick hitch below the mast pin of the implement. STEP 3: Raise the a-arms of the tractor to lift the implement. Verify that the bushings or lower hitch pins set completely within the quick hitch lower hooks and the mast pin captured by the quick hitch upper hook. - Page 9 OPERATING INSTRUCTIONS Some Non-standard CAT 1 implements may require the use of the CAT 1 quick hitch adapter. Follow the below steps to attach the quick hitch to non-standard implements. STEP 1: Remove the upper hook by removing the hex bolts and nuts. STEP 2: Slide the adapter bracket over the top bracket of the quick hitch and put the top link pin through both the quick hitch adapter and top link.
-
Page 10: Removal Instructions
OPERATING INSTRUCTIONS INSTRUCTIONS TO REMOVE THE IMPLEMENT FROM THE QUICK HITCH STEP 1: Turn off the tractor and remove the PTO driveline if applicable. See the tractor's owner's manual for instructions. Raise the tractor a-arms enough that the implement weight is on the quick hitch hooks. Flip both quick hitch handles vertical. -
Page 11: Maintenance
MAINTENANCE ALWAYS PERFORM MAINTENANCE OPERATIONS WITH THE TRACTOR’S ENGINE POWERED OFF, AND PTO DISENGAGED. Clean dirt and debris off the quick hitch after each use. Store the quick hitch in a clean and dry location. Lubricate all moving parts periodically. Check for damaged or worn parts after each use. -
Page 12: Parts List Cat 1 Quick Hitch
QUICK HITCH PARTS LIST CAT 1 QUICK HITCH P/N: 25-005 ITEM NO. PART NUMBER DESCRIPTION QTY. 07-07-02-00 TOP LINK PIN 07-09-04-00 1/4” LYNCH PIN 25-001 CAT 1 QUICK HITCH BUSHING 25-003 CAT 1 PIN 25-004 CAT 1 QUICK HITCH, BARE... -
Page 13: Parts List Cat 2, 2Hd, 3, 3N, 2/3 Quick Hitch
QUICK HITCH PARTS LIST *The photo may not be an accurate representation of the quick hitch or sub parts. CAT 2 CAT 2 HD CAT 3 CAT 3N CAT 2/3 P/N: 25-010 P/N: 25-019 P/N: 25-020 P/N: 25-021 P/N: 25-022 ITEM NO. -
Page 14: Warranty & Specifications
303-278-0664 for the location of the nearest service center. Record the information below for future reference. Model No. Serial No. (if applicable) Date of Purchase Place of Purchase SPECIFICATIONS SKU/Part No. 25-005 25-010 25-019 25-020 25-021 25-022 Model # CAT 1... -
Page 15: Registration
The warranty may be refused if the registration is not legible, completed and signed. It is the responsibility of the purchaser to assure that the registration form is received. Agknx product warranty offers one year warranty against workmanship. The warranty gives the consumer certain and specific rights which may vary from state to state. - Page 16 REGISTRATION WARRANTY VOID IF REGISTRATION IS NOT POST MAKED WITHIN 15 DAYS OF PURCHASE. Mail to: AGKNX 15000 West 44th Ave, Suite B Golden, CO 80403 Serial # (if applicable): ___________________________________________________________________ Purchase Date: __________________________________________________________________________ Purchased From: ________________________________________________________________________ Purchaser: _____________________________________________________________________________ Purchaser’s Address: ____________________________________________________________________...
