Summary of Contents for HEATKEG HP 8. 90-120 M2
- Page 1 Operation manual...
- Page 2 Importantly! This heat pump operation manual ____________ is the main guiding document for operation. It must be retained until the end of the product's service life. Please read this operation manual carefully before using your heat pump. This manual contains instructions for: installation,...
-
Page 3: Table Of Contents
TABLE OF CONTENTS General information Operational concept, application, model range Models Configuration Operating instruction (the controller guidance) Security measures Maintenance and repair. Some errors Wiring diagram of HP The diagram of the HP hydraulic connection (water/water) 24 Guarantee Warranty card... -
Page 4: General Information
(due to the small distances between the plates) does not allow such devices to connect to groundwater’s surface. The HEATKEG heat pump is unique in its segment. It is made of components that are available on the market. The HEATKEG heating system is configured to use the thermal energy, which is located underground (groundwater). -
Page 5: Operational Concept, Application, Model Range
Operational concept, application, model range The heat pump ___________ is manufactured according to the latest achievements of science and technology. Application. The heat pump water/water is designed for the space heating by using: the underfloor heating/walls and radiators of all types. The temperature of the heat transfer reaches 55°C. -
Page 6: Models
With the help of a booster, you can clean this device with nitric or other acid. Models HEATKEG HP 6. 60-90 М This model of the heat pump (HEATKEG HP 6) allows you to heat the 60 - 90 m room with a water flow from the well of 700 l/h. - Page 7 HEATKEG HP 10. 140-180 М The COMPRESSOR GMCC has 10 kW. This model of the heat pump (HEATKEG HP 10) allows you to heat the 140 - 180 m room with a water flow from the well of 2000 l/h.
-
Page 8: Configuration
Configuration The heat pump: • compressor • heat exchanger • expansion device • pressure relay The control box: • circuit breakers • heat pump controller • magnetic starter • protection relay of three-phase motor • set of sensors Rubber liners under the housing of the HP (3 pcs.) Probe for the heat transfer sensor installation (it is installed on the heating supply near the heat pump) -
Page 9: Operating Instruction (The Controller Guidance)
Operating instruction (the controller guidance) The manufacturer guarantees the proper operation of the HP (only in a case of strict observance of the instruction manual requirements). 4.1 Switching on controller After the turning on of two circuit breakers in the box (of the heat pump control), the controller will boot up and start a pause that you can skip by pressing the button . - Page 10 Compressor, Evaporator 2, Compressor 2, and the supply pressure. Returning to the main screen may be done by a short press on any button. 1 - The air temperature in the house 2 - The heat carrier temperature (it’s valid only when the compressor is on) 3 - The desired temperature in the house 4 - Maximum temperature of the heat transfer (during DHW operation, ignored)
- Page 11 After reaching the set temperature, the heat pump will turn off and turn on only after the temperature in the room drops by the set step in degrees, which are indicated in the Air Hysteresis menu section. Switching off It is carried out by a red button on the panel, or by an automatic machine in the control box for a complete de- energization of the equipment.
- Page 12 To connect to the controller, you must select the Wi-Fi network called HEATKEG in your device and click CONNECT. After connecting the device to the HEATKEG network, a page with a menu will appear on the screen of your device on which you need to press the button (Wi-Fi Scan).
- Page 13 If a smartphone (or any other device) connects to the HEATKEG access point, but the menu page does not open on its own, then you can display it manually by entering the address into the browser 192.168.4.1.
- Page 14 (Google Chrome or Safari) (in the upper right corner, click on the button and select the Add to the Home Screen). The HEATKEG application has been developed for Android users. Also, the installation link for the application is on the website www.heatkeg.com (in the upper left corner).
- Page 15 and air temperature using the buttons You can set from what time (and until what time) is necessary to work in a given temperature mode. After setting the data, briefly press “OK”. The data will be saved. After that you can exit from this page with the help of long pressing 4.7 Operating delays Launch time of the equipment delay is described on the page <3>.
- Page 16 There are an upper limit and a lower limit for the voltage in the network at which the system will generate an error. This error will automatically reset after 12 minutes. High and low voltage control can be disabled by setting the maximum and minimum values in the settings. 4.10 Customer’s information This section of the menu <7>...
- Page 17 4.12 Controller modes There are three controller modes (it is described on the page №<10>): 1) Simple mode - the standard installation 2) Master Mode - the relay №4 will energize to turn on the auxiliary or parallel heater. а) The parallel heater - parallel turning on with the compressor б) An auxiliary heater - the relay 4 will turn on when the house temperature drops to twice of the house hysteresis value.
- Page 18 controller operation logic (heating/cooling) heating - the standard setting cooling - the only difference in the logic of operation is that the compressor and the deep pump will turn off when the air temperature in the house drops to the set one, (this can be used in passive cold systems when we dump heat into groundwater or geofield), while the compressor is switched off by a single-pole compressor circuit breaker.
-
Page 19: Security Measures
Security measures In the event of a malfunction, you should contact the appropriate specialist to eliminate the breakdown. 5.1 Some operating errors can lead to personal injury or to equipment damage: ● do not allow children to play with the appliance or use it without adult supervision;... - Page 20 5.2 High temperatures There is a risk of burns due to hot surfaces and components. The risk of burns from a hot liquid. There is a risk of burns from hot water (when using hot gas cooling and high-temperature heat pumps up to +65 °C or more).
-
Page 21: Maintenance And Repair. Some Errors
Maintenance and repair. Some errors 6.1 Repairs may be carried out only by specially trained and qualified staff. 6.2 Installation and implementation The heat pump installation and implementation is carried out by specialized companies or specialists authorized to carry out such work. 6.3 Errors Error Description... - Page 22 The error is reset automatically after the mains voltage stabilizes. The heat High voltage in the pump will restart itself after 12 "high volt" network minutes. "380 voltag." 380 network error The incorrect network parameters 380. Check the presence of phases, or swap two phases for changing the direction of rotation.
-
Page 23: Wiring Diagram Of Hp
Wiring diagram of HP Single phase heat pump Lilac symbol - input L and N Connection of a single-phase HP to the network is carried out with an aluminum cable sip 2 * 16 or copper 2 * 4 mm 1) the borehole pump and the heating circulation pump. -
Page 24: The Diagram Of The Hp Hydraulic Connection (Water/Water)
The diagram of the HP hydraulic connection (water/water) -
Page 25: Guarantee
Guarantee In case of failure of any heat pump unit or the entire system during the warranty period, due to the fault of the manufacturer, the manufacturer will either repair the heat pump or the defective unit or replace the entire equipment. The manufacturer is not responsible for damages arising from the inappropriate use of the equipment or storing, or its transportation. -
Page 26: Warranty Card
Warranty card Model Serial number Date of manufacture Date of sale Price, UAH. The name and address of the seller Buyer information Full name. Tel. The goods were received in a good condition and it was complete. I am acquainted with the terms of the guarantee and agree on it. - Page 27 Thank you for purchasing a heat pump!
