- Page 1 Dual Light Pod ZX-P-IV-D-GL80 Shenyang Sumboy Intelligent Imaging Technology Co.,Ltd. January 2019...
-
Page 2: Table Of Contents
Contents 1 Introduction..................................1 2 Product Structure and Electrical Interface........................1 2.1 Size of Product................................ 1 2.2 Electrical Interface..............................2 2.3 Connection diagram............................... 3 3 Product and accessories..............................4 4 Operation instruction of software............................ 5 4.1 Home..................................5 4.2 Operating process..............................5 5 Precautions..................................8... -
Page 3: Introduction
Dual Light Pod Manual 1 Introduction Model of ZX-P-IV-D-GL80 ， the pod uses 10X optical zoom camera and un-cooled infrared camera, and achieves high definition image quality, excellent auto-focus performance as well as function of target tracking. With the two-axis and two-frame system, the product arrives at higher precision in image stabilization and no over-top dead zone. -
Page 4: Electrical Interface
2.2 Electrical Interface 2.2.1 External Interface 1) Power interface: 10-16V; 2) 1 way RS232, asynchronous serial interface, 8 data bits, 1stop bit, no parity, baud rate 115200bps; 3) Network/Synchronization 422 compressed video interface; 4) Default card1. 2.2.2 Interface Definition J30-15 connection interface definition Interface Remarks 10V~16V... -
Page 5: Connection Diagram
2.3 Connection diagram... -
Page 6: Product And Accessories
3 Product and accessories 1）ZX-P-IV-D-GL80 Pod: 1 set; 2）J30-15 connecting line: 1 piece. ZX-P-IV-D-GL pod + video processing module×1 J30-15 connecting line×1 Please plug in the power finally to prevent damage to the machine. Please pay special attention to the position of the socket pins. -
Page 7: Operation Instruction Of Software
4 Operation instruction of software 4.1 Home 4.2 Operating process Power on 1. Connect the video source and control serial port to the computer; 2.Open the software. Confirm port number and network port settings Right click on the computer, select computer property as shown on the right;... - Page 8 Double click the port(COM and LPT),the refreshed USB port is which need to be selected. Click drop-down list of serial port, select the right serial port number(status: turned on;the connection is correct) Choose the video source: 1. If you access the video through USB capture card, you can select the USB video, skip the next step and open the video directly.
- Page 9 Track: double-click the left button of the mouse in the video stream to select the tracking target to realize the function, click the “stop track”button to cancel tracking; Click the “track”button to center the cross cursor; Template size: the size of the tracking frame template can be adjusted by the template size.
-
Page 10: Precautions
5 Precautions 1) The daily maintenance of the operating personnel is limited to the replacement or inspection of cables, daily cleaning and maintenance, and functional inspection to ensure that the instrument is in good technical condition. 2) Do not open the case without authorization. There are no user-serviceable parts inside the machine. When the system fails, the fault is located by the manufacturer's technology and then processed.
