- Page 1 WAIST HEIGHT TURNSTILE INSTALLATION AND MAINTENANCE HANDBOOK WARRANTY CERTIFICATE www.ozak-t.com KK-1302-0001 R(11) 29.03.2022...
- Page 2 INDEX GENERAL INFORMATION ............................4 1.1. Preface 1.2. General Information on Turnstiles 1.3. Waist Height Turnstile Models SAFETY AND OPERATION ............................5 2.1. Safety Warnings and Symbols 2.2. Power Supply Fuse 2.3. Safety Related Instructions 2.4. Operating Conditions HANDLING AND INSTALLATION ..........................6 3.1.
-
Page 3: General Information
E-mail or telephone. Özak Technical Service Department: Telephone : +90 262 373 48 48 Ext: 1301-1304 E-mail : support@ozak-t.com Özak reserves the right to change the contents of this document without prior notice! 1.2 General Information on Turnstiles Turnstiles are devices that enable passage control and prevent uncontrolled or unauthorized passages in stadiums, sports halls, leisure facilities, business centers, public transportation areas, museums, banks, industrial facilities and all premises where collective entrance and exit control are required. -
Page 4: Grounding Symbol
2. SAFETY AND OPERATION 2.1 Safety Warnings and Symbols For Safety and proper operation of the turnstile, all installation and repair work must be performed by qualified technical personnel only! HIGH VOLTAGE WARNING LABEL WARNING / DİKKAT WARNING ! 220 V. 50 Hz. Never remove the protective cover of the power supply unit for any reason! Gnd. -
Page 5: Safety Related Instructions
2.3 Safety Related Instructions Users must not dismantle the turnstiles. Maintenance can only be performed by competent and authorized personnel. Maintenance work attempted by non- qualified individuals may create danger to users and the turnstile. Turnstile must not be installed at places where there is a risk of explosion caused by electrical arcs or a probable gas leakage. - Page 6 3.2.1 Installation Illustrations For Different Surface Mounting Bracket Versions Electronic Main Board SMPS KONTROL KARTI 220 V AC Surface Mounting Bracket Shaded areas for cable routing ~67 mm (*) Measurements vary according to model. Power and Control Wiring Turnstile Body Surface Mounting Bracket Wire Routing...
- Page 7 3.3 Arm Mounting (Fixed Arm Models) Arm must be mounted correctly to prevent loosening and dropping during use! CORRECT INSTALLATION Rotor Rotor Arm Rotor Head Washer WRONG INSTALLATION M10 Lock Washer M4x15 Allen Screw Rotor Head Bolt M4 Star Washer Rotor Head Cover M4x10 Allen Screw CORRECT...
- Page 8 3.5. Wing Mounting (Wide Access/ DDA models) 1. Insert panel in place. 2. Tighten top xing screw 3. Tighten bottom xing screw 4. TURNSTILE SYSTEM SPECIFICATIONS 4.1 Waist Height Turnstile System Specifications Table MECHANISM OPERATIONAL FEATURES MATERIALS WAIST HEIGHT MODELS ARM / WING MANUEL MOTORIZED...
- Page 9 4.2 System Specifications – Tripod Models 500 E/500 E N1 400 E 400 BUS 500 E-D/500 E-D N1 702 R/702 R N1 702 B 602 D 700 E/700 E N1 700 E-D/700 E-D N1 700 R FKR 777 System is designed for bi-directional operation. In standard models, when power is cut off, arms freewheel to allow free passage in both directions;...
-
Page 10: Equipment And Accessories
4.3 System Specifications- Wide Access/ DDA Models-Turnstiles For Reduced Mobility 705 E/705 E N1 705 E-D/705 E-D N1 605 D 715 B 715 E 605 D Microprocessor controlled, bi-directional wide access system (Only 715-B ve 715-E models are uni- directional) PWM DC motor driven system for quiet and efficient operation. -
Page 11: Power And Grounding Connections
Ozak. materials! SMPS Control Board 3 x 1,5 TTR Power cable minimum 2 meters above... - Page 12 5.2 Control Board Inputs and Outputs For TRN 1203 I/O_1 I/O_2 I/O_3 I/O_4 Out_P3 Out_P2 Out_P1 +5 V +24 V Solenoid Out Direction Sensors - Power + *Motor Control (Motorized Models)
- Page 13 For TRN 1901 - Power + Direction Sensors *Motor Control (Motorized Models)
- Page 14 For TRN 2101 S/E Buzz.On/O Direction Sensors - Power + + Motor Out -...
-
Page 15: Control Inputs
5.3 Control Board External Component Connections For TRN 1203 Solenoid A-B Top Passage Indicator and Buzzer Side Indicators Top Indicators Motor Control Side indicators Optional Comm. Port Solenoid B-A Direction Photo Sensor +24V Motor Control N.O. Power Input (24 VDC) Dip Switch N.O. - Page 16 For TRN 1901 Solenoid A-B Solenoid Out Motor Out Side Indicators Top Indicators Solenoid Out Top Indicator Side Indicator Outputs USB Comm. Port N.o. Solenoid B-A Direction Photosensor Inputs N.o. Motor Control (Motorized Models) N.o. Power Inpıt RL AL RL B RL A Dip Switch InhB...
- Page 17 For TRN 2101 S/E + Battery - Solenoid Out External out Side Indicators Top Indicators Solenoid Out N.o. N.o. N.o. RL AL RL B RL A InhB EXT1 InhA 1 2 3 4 +24 V Out 1 In 2 In 1 11.
- Page 18 Wiring Diagram For AVIR 800 Only...
- Page 19 5.4 Control Board Settings 5.4.1 Blocking Passage Direction For TRN 1203 To block entry into A or B direction, short enable pins (J4,J5). Turnstile will not allow passage in the blocked direction and indicator for that direction will turn red to show blocked access. This feature can be used with a metal detector to automatically block access for security purposes or setting the turnstile for one way traffic operation.
-
Page 20: Dip Switch Settings
5.4.2 Dip Switch Settings • Tripod Turnstiles: Time out and mode settings of the turnstile are selected by the dip switch located on the control board as explained below. SWITCH NO EXPLANATION TIME SETUP 1 TIME SETUP 2 PROGRAM SETUP 1 PROGRAM SETUP 2 TIME SETUP DIPSWITCH... - Page 21 5.4.3 Magnetic Encoder Arm Stop Settings TRN2101 Control Board / 3 and 4 Arm Turnstile Rotor Arms Centre Position Settings System reset and service/ adjustment mode Prog Reset TRN2101 Control PCB ‘Prog’ and ‘Reset’ buttons. Press and release reset button. Press and hold ‘prog’ Button while system reset buzzer warning is on.
- Page 22 TRN2101 Control Board / GLA, DDA Gates Wing Position Settings System Reset and Service/ Adjustment Mode Prog Reset TRN2101 Control PCB ‘Prog’ and ‘Reset’ buttons. Press and release reset button. Press and hold ‘prog’ Button while system reset buzzer warning is on. Release ‘prog’ Button when rapid beep is heard. This activates manual command service mode.
-
Page 23: Damper Adjustment
5.5 Hydraulic Damper Settings (Manual Models) Hydraulic Damper Adjustment: Damper Due to large variations in ambient temperature 1.2 mm. Allen or wear, the hydraulic damper adjustment may be required. Example; in very cold temperatures damping should to be reduced if the rotor can not quickly return to rest position following rotation. -
Page 24: Post-Installation Checklist
Inspect external mounting screws, panels, arms etc. once every three months or as required to ensure that there are no loose, worn out or damaged items. If there are loose or damaged items contact your authorized dealer or Ozak. •... - Page 25 7.1.2 Periodic Maintenance by Technical Service Personnel 400-500-600-700 SERIES TURNSTILES General Cover and anchoring bolts 12 mth. Check/ Tighten Cover, reader and indicator seals 12 mth. Check Rotor head and mounting hardware 12 mth. Check Mechanism Rotor shaft 12 mth. Check + Lubricate Damper arm and bearing 12 mth.
- Page 26 Description of Fault Possible Cause Recommended Action 1. Loose or broken clamp spring 1. Re-install / replace clamp spring Rotor/arms do not return to center 2. Over damped hydraulic damper 2. Adjust hydraulic damper (see 5.5) (standby) position following a passage setting Rotor bounces back and forth 1.
- Page 27 Solenoid (5V) 30 01 11 0004 Top Indicator (Type 1) 30 01 02 0121 Top Indicator (Type 2) 30 01 05 0050 Magnetic Encoder** **Units with magnetic encoder do not include direction photosensor (ref 1) Use only original Ozak replacement parts!
- Page 28 **Units with magnetic encoder do not include direction photosensor (ref 1) Use only original Ozak replacement parts! * Please provide model and serial number of the turnstile when ordering parts. **Specify firmware code for microprocessor orders ! Parts may vary according to model and manufacturing date !
-
Page 30: Warranty Terms And Conditions
Republic of Turkey Ministry of Industry and Trade, Directorate General of Protecting Consumer Rights and Competition. 11. All replacement parts sold by Ozak are warranted for a period of one year following the date of purchase, excluding failures resulting from physical damage, incorrect installation, misuse, tampering and similar reasons beyond manufacturers control. -
Page 31: Ce Declaration Of Conformity
9.4 CE Declaration of Conformity CE UYGUNLUK DEKLARASYONU / CE DECLARATION OF CONFORMITY ÜRETİCİ FİRMA/ : ÖZAK GEÇİŞ TEKNOLOJİLERİ SANAYİ TİC. A.Ş. MANUFACTURER COMPANY ADRES/ADDRESS ÇUHANE CAD. NO: 130 41080 KÖSEKÖY/KOCAELİ/TÜRKİYE Aşağıda adı geçen ürünlerin üretimi, kontrolü ve son değerlendirmeleri ÖZAK tarafından gerçekleştirilmektedir. Manufacturing, control and final assessment of the below mentioned products are done by ÖZAK. - Page 32 +90 262 373 48 48 3 48 8 48 48 8 48 48 +90 262 373 48 48 3 48 48 4 48 48 E: ozak@ozak-t.com DD-75-80 (R0) - 03.03.2015 z z o o o o o z KK-1302-0001 R(11) 29.03.2022...
