Ecovim Eco-250 Quick Manual

Getting Started:

Electrical Requirements:

The system requires 208 – 220 volt, three-phase, 30 amps, 4 wire system WYE Wired and will
run on 50 or 60 HZ.
This electrical connection should be a straight run back to the panel and the breakers marked
to distinguish the Eco - 250 connections from any other installed service.
You must supply both electrical connectors for your site
1. Wall to electrical panel
2. And System to wall
Your electrician will be able to assist you with these requirements.

Physical Requirements: (45.3"*39.4"*41.4")

The Eco - 250 units come with casters that lock for easy positioning of the unit.
The unit can be placed outside provided that the unit is protected from the elements.
Rain, snow and ice can and will damage the electrical portions of the unit.
A drain line, to remove condensate from the system is included. The condensate can then go
directly to the main drain as it contains no chemicals or sediments and is gravity fed.
The drain must be below the output from the unit and must drain away from the unit to insure
fluid movement.
A heater switch for the water reservoir is provided for colder climates to keep the water from
freezing (see operator manual)
