Summary of Contents for SecuLock ND-P Series
- Page 1 ND-P Series P6000, P6100, P6200 P7000, P7100, P7200 A non-key door lock may be partially broken to open the door when it malfunctions. If it is a key door lock, keep the key with in your reach in case of emergency.
-
Page 2: Table Of Contents
Safety Precautions Products Specifications/Components Parts Name PIN-codes Activation/Deactivation Card keys Activation/Deactivation Remote Controllers Activation/Deactivation Fingerprints Activation/Deactivation Double Authorization Mode Pre Authentication Mode Opening Door Opening the door from outside Opening the door from inside Locking Door Locking the door from outside Locking the door from inside Safety Lock Mode Automatic / Manual Lock Mode... -
Page 3: Safety Precautions
PIN-codes... -
Page 4: Products Specifications/Components
Authentication Method Model PIN-code Card Key Fingerprint Emergency Remote Mobile (up to 10) (up to 30) (up to 100) Controller Key (2ea) P6000 P6100 Refers to P6200 up to 5 P7000 manual P7100 P7200 ※ Remote Controller / Mobile App are optional. 40-50mm 61 - 90mm (Optional shafts &... -
Page 5: Parts Name
▲ ▲ ▲ ▲... -
Page 6: Pin-Codes Activation/Deactivation
PIN-codes Activation/Deactivation PIN-codes Activation PIN-code Beep PIN-code PIN-codes. PIN-codes Deactivation registered PIN-code PIN-codes PIN-codes, PIN-code Beep... -
Page 7: Card Keys Activation/Deactivation
registered PIN-code Beep before Beep PIN-code Beep... -
Page 8: Remote Controllers Activation/Deactivation
Remote Controllers are not provided with a standard package. When using Remote Controller or Mobile App, we highly recommend you to prepare 4EA more batteries in additional for stable use. Open the battery cover, press the button shortly. When the numeric touch plate is on, enter the registered PIN-code with the [ ] button. -
Page 9: Fingerprints Activation/Deactivation
To raise the recognition rate, we highly recommend you to add same fingerprints in different conditions. registered PIN-code Beep Press number [4], number ‘1 2 3’ will blink. Press your finger on the panel 3 times, after the registration the buzzer will sound. PIN-code Beep... -
Page 10: Double Authorization Mode
_ 10 Double Authorization Mode Double Authorization Mode Activation Double Authorization Mode requires two different authentications registered to activate. ( e.g. [PIN-code] + [Fingerprint], [PIN-code] + [Card Key] ) Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code. -
Page 11: Pre Authentication Mode
_ 11 Pre Authentication mode is default mode. Please enter the PIN-code first to enter the setting mode. Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code. the process, buzzer sound “Bi-ri-ri-rik”. Bi-ri-ri-rik Touch the numeric touch plate gently, then the touch plate turns on. -
Page 12: Opening Door
_ 12 Opening Door Opening the door from outside Using PIN-codes Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code and then [ ] button. Security Random PIN-code function This is a function to prevent the private PIN-code from exposing to other people, any number can be entered before or(and) after the authentic PIN-code. -
Page 13: Opening The Door From Inside
_ 13 Opening Door / Locking Door Opening the door from inside Using Handle Using [OPEN/CLOSE] button Pull or Push the handle of the inner body when the door is locked, then the door will open. If the door is not opened for 7 seconds after it is unlocked by using a button, the door is locked automatically in the automatic locking mode. -
Page 14: Safety Lock Mode
_ 14 Safety Lock Mode Outdoors It is a function to prevent intruders from opening doors by manipulating an internal handle or button. Warning Alarm goes OFF for once. Warning Alarm will be released when the door is opened using the authentication method registered from outside. Activating Safety Lock Mode When the door is locked, touch the numeric touch plate gently, then the touch plate turns on. -
Page 15: Automatic / Manual Lock Mode
_ 15 Automatic / Manual Lock Mode Automatic Lock Mode Automatic Lock Mode is the default mode. The door is automatically locked when it closes. However, make sure that the door is completely closed when going outside. Press the [OPEN/CLOSE] button to make the dead bolt come out when the door is open. -
Page 16: Volume Setting
_ 16 Volume Setting Silent Mode Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code with the [ ] button to open doors. Volume Setting User can change the volume of the button sound. Available only when the door is locked. -
Page 17: Fire Detection Alarm
_ 17 PIN-codes, Intrusion Alarm If someone tries to break-in or damage the door by force while the door is locked, it alarm goes off loudly. Intrusion Alarm Off PIN-codes If an attempt is made to open the door with invalid PIN-codes, Card Keys, and Fingerprints five times in a row, the warning alarm goes off and the touch plate will not work for 1 minute. -
Page 18: Low Battery
_ 18 Low Battery If the red battery icon is ON with an alarm, please replace all batteries. Please do not mix old and new batteries. Make sure batteries are placed in correct poles. Emergency Power Use The product will not operate if the batteries are fully discharged, please follow the steps bellow. -
Page 19: Trouble Shooting
_ 19 Problem Trouble Shooting ㆍMake sure the batteries are placed in correct poles(+/-). Door Lock not ㆍIf the batteries are completely discharged, replace all batteries turning on with new ones. (LR6 1.5V AA Alkaline batteries only) Cannot change ㆍRegister PIN-codes again, refer to the user’s manual. (page 6) PIN-codes Cannot change ㆍRegister Card keys again, refer to the user’s manual. - Page 20 Scan to play video channel Operation Guide Push Pull Lock Neurosys Co., Ltd. made in Korea NE v.2.3...
