- Page 1 Please read this user manual carefully before installation. TCMK5413W Wireless Input&Output Module User Manual Liaoning·Tiancheng Fire Protection Equipment Co., LTD...
- Page 2 Version Date Author Note Ver1.0 202009 Nov. 16, 2020 Deng Yi, Yan Chong Create...
- Page 3 Ver1.0 202010 I. General The TCMK5413W wireless input/output module (hereinafter referred to as the module) is suitable for installation in public places, factories and other environments. When there is a fire alarm, the module can send an alarm signal to the controller through wireless communication technology after receiving the closing signal, or it can output the closing signal to connect to other equipment.
- Page 4 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 II. Features 1. Adopting 470MHz wireless communication technology, no need to pre-buried wiring, easy and quick engineering installation; 2. With battery low-voltage detection function, it can reflect the battery power status in time; 3. Use microprocessor to realize signal processing, and use digital signal to communicate with controller, work stably and reliably, and have good suppression ability against electromagnetic interference.
- Page 5 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 9. Reset method: by control panel 10. Application environment： Type：indoor Atmosphere pressure：86kPa～106kPa Temperature：-10℃～+55℃ Relative humidity≤95%，non-condensing 11. Outline dimension：101mm×137mm×43mm 12. Material and color：ABS, off-white 13. Weight：about 170g (including battery) 14. Executive standard：GB 16806-2006 "Fire Linkage Control System" XF 1151-2014 "General Requirements for Wireless Communication Functions of Fire Alarm Systems"...
- Page 6 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 When the module input terminal receives the closing signal, it sends an alarm signal to the control panel through wireless communication technology, and the module input indicates that the red light is always When the module receives the control signal from the control panel, the module outputs a closing signal to connect to other devices, and the module output red light is always on.
- Page 7 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 Fig.3 Installation hole distance AS1,AS2: Passive answer signal input OUT1,OUT2: Passive normally open output Fig.4 Wiring diagram 辽宁•营口天成消防设备有限公司...
- Page 8 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 V. Test Warning: Please make sure that the polarity of the battery is correct before proceeding. 1. After the module is installed and tested every year during use. 2. Alarm test: After the networking is successful, choose a module to artificially make it meet the alarm conditions (please turn off the fire alarm linkage function to avoid unnecessary alarm linkage), after the test, power on again, and notify the relevant management department Restore the system to normal.
- Page 9 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 4. Output start: when the module receives the control signal from the control panel, the module outputs a passive close signal, which can be connected to other devices, and the module output red light is always on. 5.
- Page 10 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 times every 48s above-mentioned multiple faults one by one After the device alarms, the The device is not connected to the Restart the network operation controller has no status prompt network Move the device near the controller, Device networking Too far away from the controller or...
- Page 11 JTY-GM-TC5401W 无线点型光电感烟火灾探测器安装使用说明书 Ver1.0 202010 Liaoning·Yingkou Tiancheng Fire Equipment Co., Ltd. Address: No. 11-2, Kechechang Xili, Xishi District, Yingkou, Pilot Free Trade Zone (Liaoning) China , City Fax: 0417-4835568 Postcode: 115004 Tel：400-6930-119 Email: info@tcfiretech.com Website: www.tcfiretech.com 辽宁•营口天成消防设备有限公司...
