MOKENEYE AG01Z Owner's Manual

20v cordless brushless angle grinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
VERSION: AG01Z-EN-03
4-1/2" & 5"
20V CORDLESS BRUSHLESS ANGLE GRINDER
Model
AG01Z
NOTICE: Get 1-year extended warranty by scanning the QR code to REGISTER.
To reduce the risk of injury, the user must read and understand the
WARNING:
Owner
's Manual before using this product. Save these instructions for future reference.
support@mokeneye.com
For Customer Service
www.facebook.com/MokeneyeTools

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AG01Z and is the answer not in the manual?

Questions and answers

Summary of Contents for MOKENEYE AG01Z

  • Page 1 Owner’s Manual VERSION: AG01Z-EN-03 4-1/2" & 5" 20V CORDLESS BRUSHLESS ANGLE GRINDER Model AG01Z NOTICE: Get 1-year extended warranty by scanning the QR code to REGISTER. To reduce the risk of injury, the user must read and understand the WARNING: Owner 's Manual before using this product.

  • Page 2: Table Of Contents

    operated (cordless) power tool. TABLE OF CONTENTS WORK AREA SAFETY • Keep work area clean and well lit. Cluttered or dark areas invite accidents. GENERAL SAFETY WARNINGS ....2 • Do not operate power tools in explosive SAFETY WARNINGS FOR ANGLE GRINDER ..3 atmospheres, such as in the presence of flammable liquids, gases or dust.

  • Page 3: Safety Warnings For Angle Grinder

    • Do not overreach. Keep proper footing and • Recharge only with the charger specified by the balance at all times. This enables better control manufacturer. A charger that is suitable for one of the power tool in unexpected situations. type of battery pack may create a risk of fire when used with another battery pack.
  • Page 4 accessory must be within the capacity rating of may result in electrocution or shock. your power tool. Incorrectly sized accessories FURTHER SAFETY INSTRUCTIONS FOR cannot be adequately guarded or controlled. ALL OPERATIONS • Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted by flange, the arbor hole of the Kickback and Related Warnings: accessory must fit the locating diameter of the...

  • Page 5: Symbols

    operator from broken wheel fragments, NOTICE: Equipment and/or property damage may accidental contact with wheel and sparks that result if these instructions are not followed. could ignite clothing. The operation of any power tools • Wheels must be used only for recommended can result in foreign objects being applications.

  • Page 6: Get To Know Your Angle Grinder

    GET TO KNOW YOUR ANGLE GRINDER MOKENEYE 20V CORDLESS ANGLE GRINDER SPINDLE LOCK VENTILATION OUTLET SWITCH BUTTON CONTROL PANEL SPINDLE WHEEL GUARD BACKING FLANGE GRINDING WHEEL LOCK NUT 10) AUXILIARY HANDLE 11) LED LIGHTING 12) VENTILATION AIR INLET SPECIFICATIONS Rated voltage 20V d.c.

  • Page 7: Accessories

    ACCESSORIES Fig. Name Fig. Name Auxiliary Handle Wheel Guard Backing Flange Wrench Compatible with both 4-1/2" x 7/8" (Ø115 x 22mm) Lock Nut 5" x 7/8" (Ø125 x 22mm) Grinding Wheels Using accessories not designed for this tool can cause serious injury. 13) BATTERY PACK 14) CHARGING INDICATOR...

  • Page 10: Operating Instructions

    NOTICE: If the charger does not charge the battery manuals for detailed operating information. pack under normal circumstances, return both the battery pack and charger to your nearest Mokeneye FUEL GAUGE BATTERY PACKS Authorized Service Center for electrical check. Some MOKENEYE battery packs include a fuel gauge •...
  • Page 11 If the green LED continues to remain on, on the spindle. It will click into place on the return battery pack to your nearest Mokeneye spindle and will cause the spindle to rotate when Authorized Service Center for checking or replacing.

  • Page 12: Grinding Operations

    is in low-speed mode and capable of providing To detach the battery pack: up to 5,000 RPM. Depress the battery-release button, located on the 2 LED indicators are on, indicating the tool is front of the battery pack, to release the battery pack. in high-speed mode and capable of providing Pull the battery pack out and remove it from the tool.

  • Page 13: Maintenance

    MOKENEYE warrants to the original purchaser only, components which could cause serious hazard. We that all MOKENEYE consumer POWER TOOLS will be free from defects in material or workmanship for a recommend that all tool service be performed by a MOKENEYE Factory Service Center or Authorized period of one years from date of purchase.
