Summary of Contents for Mintion Beagle
- Page 1 PACKING LIST Beagle camera Power Type C Cable USB-Micro-B Plug x1 1.5M x1 Cable 1M x1 (For power) (Connect to printer) Quick Guide Manual Micro SD Reset Quick Guide Card x1 Needle x1 Manual x1 (Insert in camera)
-
Page 2: Specification
SPECIFICATION Part Number Beagle Night Version Frame Rate Up to 25fps Upload Printable File Yes, Only gcode files Compatibility of 3D Printers Marlin firmware Videos/Printable Files Storage Micro SD Card Connect to Printer USB Cable Video Compress H.264/H.265 Camera Resolution... -
Page 3: Camera Introduction
CAMERA INTRODUCTION IR-Cut Sensor Lens Microphone Camera Base... - Page 4 WiFi Printer WiFi Indicator Printer Indicator Solid Red: Solid Green: Printer connected WiFi connected Flashing Red: Flashing Green: Printed disconnected WiFi disconnected Speaker USB Socket...
- Page 5 Type-C Socket (Power) Plug and hold for 5 seconds, and you will hear the voice of "Successfully resetting the camera", then the camera will be reset and restart. Micro SD Slot...
-
Page 6: Connecting Cables
CONNECTION Connecting Cables Plug the power cable into the camera and the power adaptor, then into a power outlet, plug the USB-Micro-B Cable into the camera and the 3d printer, as shown in the figure below. (The camera will take 1-2 minutes when power-up, don't cutoff the power during this period.) Power outlet Connect to Printer... - Page 7 APP DOWNLOAD & REGISTRATION Beagleprint App Store Google Play Download Download Download Please scan the QR Code to reach the App download page, then download from App Store, Google Play or download the APK directly. After download,Click to run the app and make the registration. USE THE APP WiFi Use your phone to connect to the...
- Page 8 Make sure the power is not being cut off during the configuration. XXXXXX XXXXXX Select your WiFi and then input the password to save the WiFi information in the app.
- Page 9 Go to the "Setting" interface of your mobile phone to connect the camera hotspot. The camera will automatically connect to the WiFi network. Please wait for 1-2 minutes.
- Page 10 Click the camera image to log in and then connect the camera to your printer. Click the “Connect” button to connect the camera to the printer, then you can control the printer through the camera.
- Page 11 ATTENTION DO NOT Please cut off the power of the Beagle camera when it's DO NOT working; disconnect the camera from the printer when it is connected to the printer and transmit printable files through the camera for 3d printing. Otherwise, it will cause printing failure and damage the camera's firmware.
-
Page 12: Fcc Warning Statement
FCC WARNING STATEMENT Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 13 The maximum storage is 128GB. What's the camera lens? And what's the distance? The beagle camera is using the fixed lens, and the focus distance is 20cm. How can I connect the Beagle camera to the printer? We provide the default micro USB to USB cable inbox to connect to the printer, if your printer is using a Hi-speeding 2.0 socket, you have to...
- Page 14 GUIDELINES OF BEAGLE CAMERA Setup for WiFi Connection Unboxing and Setup Time-lapse Video 3D Printers IP Address on PC Firmwave Ungrade of compatibility SHENZHEN MINTION TECHNOLOGY CO., LTD Webside: www.mintion.net Distribution: sales@mintion.net Support: support@mintion.net FB Group: Mintion Official Group (Beagleprint)
