SB-CM-T-M-BL
Weatherproof Ceiling Mount for Medium TVs
Install Guide
We recommend this product be installed by a qualified professional. Do not install if you have doubts
regarding the effectiveness or safety of an installation method.
Product Details
Specifications
Maximum Load: 36.4 kg (80 lb)
Extension: 0.46m (1.5 ft.)
Stainless steel hardware
Pan/swivel range: 360°
Tilt range: +0°/-20°
Weather-resistant coating
VESA: 100×100, 200×100, 200×200
Hardware Kit Contents
Bag 1
(B) 19×8.4×2
(A) ST8 × 63 lag bolt (×6)
washer (×10)
Bag 2
(G) M6 × 12 mm
(H) M6 × 20 mm
Torx screw (×4)
Torx screw (×4)
Bag 3
(O) M10 × 70 mm screw with lock nut (×1)
Unmarked Bag
Security wrench T20
Security wrench T25
Box Contents
Ceiling plate assembly (1)
Mounting head (1)
Adapter plate (1)
0.46m (1.5 ft.) extension pole (1)
Hardware kit (see below)
(C) M4 × 12 mm
(D) M4 × 20 mm
Torx screw (×4)
Torx screw (×4)
(I) M6 × 30 mm
(J) M8 x 16 mm
Torx screw (×4)
Torx screw (×4)
(P) M5 x 4 mm set screw (x6)
Security wrench T30
Security wrench T40
(E) M5 × 12 mm
(F) M5 × 30 mm
Torx screw (×4)
Torx screw (×4)
(K) M8 x 20 mm
(L) M4/M5/M6 spacer
Torx screw (×4)
12 mm (×4)
(Q) M6 × 10 mm
(R) 15 × 6.5 × 1.5 mm)
Torx screw (×2)
metal washer (×2)
Hex wrench, 2.5mm
Tools Required
Power drill
3/16" (5 mm) drill bit
5/16" (8 mm) masonry bit
1/2" (13 mm) wrench
3/8" socket wrench
7/16" socket wrench
Optional: Security Torx bit
sizes: T20, T25, T30, T40
(M) M5 (16×5.3×1.5 mm)
(N) M6 (18×6.5×1.5 mm)
metal washer (×4)
metal washer (×4)
1
Advertisement
Summary of Contents for Snap One SunBrite SB-CM-T-M-BL
- Page 1 SB-CM-T-M-BL Weatherproof Ceiling Mount for Medium TVs Install Guide We recommend this product be installed by a qualified professional. Do not install if you have doubts regarding the effectiveness or safety of an installation method. Product Details Specifications Box Contents Tools Required Maximum Load: 36.4 kg (80 lb) Ceiling plate assembly (1)
- Page 2 Warnings Do not begin installation until you have thoroughly read and understood these instructions. Failure to comply with these instructions could result in damage to the product, or serious injury, or death. The manufacturer does not accept responsibility for incorrect installation. Do not install if any parts are missing or defective.
- Page 3 Attach the Extension Pole Thread the extension pole into the bracket. Screw it in, ensuring the holes in the pole align with the holes in the bracket. Slide the safety bolt (O) through the bracket and pole, and secure it with the safety nut (O). Insert and tighten the set screw.
- Page 4 Snap One, LLC, in the United States and/or other countries. Control4, SunBriteDS, and SunBriteTV are also registered trademarks or trademarks of Snap One, LLC. Other names and brands may be claimed as the property of their respective owners. Snap One makes no claim that the information contained herein covers all installation scenarios and contin- gencies, or product use risks.
