Summary of Contents for Fastpong FP01
- Page 1 Fastpong Instruction Manual The next evolution in table tennis training Instruction manual for the Fastpong table tennis training system (FP01) and optional external display (ED01) Download the latest version from www.fastpong.com © 2022 Fastpong Corp.
-
Page 2: Registering The Device
Introduction Thank you for purchasing the Fastpong system. It is unlike any other system on the market. It is designed to make table-tennis training both more effective and more enjoyable. We believe it to be an invaluable tool for players of all levels from amateur to professional as well as an excellent tool for coaches and clubs. -
Page 3: General Safety Information
• Regularly check the appliances for broken parts and/or damaged cords. Do not use if you find that it is damaged, contact Fastpong. • This device is not suitable for young children without careful adult super- vision. - Page 4 Certification This product has the following certifications / complies with the following stan- dards: 1. CE : compliance with the relevant EU legislation and the product may be sold anywhere in the European Economic Area (EEA). 2. FCC :the product has been tested to comply with FCC (Federal Commu- nications Commission) standards and it has been approved.
-
Page 5: Box Contents
Box Contents Your package should contain the items listed below. Optional items are for sale separately. • Board 1, Board 2, Board 3, Board 4 (see Figure 2a) • Power adapter (see Figure 2b) • Ball sensor (see Figure 2c) •... - Page 6 Parts, Ports and Switches The side of board 1 (see Figure 4) has the following ports, buttons and switches. 1. DC 12V in socket. 2. Power switch 3. Reset score button 4. Change mode button 5. Ball sensor socket 6. External display socket Figure 4: Ports...
-
Page 7: Setting Up The Device
Setting Up the Device There is a quick set up video on the website in the support section. 1. Place the boards on the table tennis table as shown in the diagram for training modes using the ball shooter, (see Figure 5). If you are setting up for reaction mode then you will either need to remove the ball shooter (or place the tiles at the other end of the table). - Page 8 Figure 5: Placement of tiles on the table tennis table Figure 6: Ensure that tiles are firmly pushed together Figure 7: Attaching the ball sensor to the robot ball shooter. This may be different depending on your model and brand of ball shooter...
-
Page 9: Using The Device
Using the device The device operates in different modes. These modes can be entered using either the buttons on the device or using the mobile application. Pressing the Mode Button will change the mode. A list of the modes and their order is shown in Figure 10. - Page 10 Reaction Mode Reaction mode is used to train your reaction time. In this mode (see Figure 9), a random tile will light up after a random period. When you tap the correct tile, the light will switch off again. The display will show the number of tiles that have lit up so far and your last reaction time.
- Page 11 Training Mode − sequential 7A5 P1 Training Mode − random 7Ar P1 Reaction Mode r3Ac7 P1 Game Mode 1 E1 P1 Game Mode 2 5nAHE P1 Game Mode 3 E3 P2 Display Mode FA57Pon9 Diagnosis Mode d1A9no51 Figure 10: Modes available by pressing the mode button...
-
Page 12: Mobile Application
Mobile Application FastPong’s device is designed to be used with our mobile app (see Figure 11), which allows you to access different features of the device and fine tune many of the settings. The app will enable you to log your training data for more detailed analysis of your performance, strengths and weaknesses, and track and share your progress. -
Page 13: Specifications
Specifications The company reserves the right to improve and upgrade products. Product specifications and design are subject to change without notice. FastPong Training System FP01 Physical total 14 ± 1 kg Weight Size(W x L x H) each board measures 76cm x 38cm x 2.4cm...
