- Page 1 SCAN ME For helpful tips and how to videos USER GUIDE Please read this User Guide carefully before use and keep for future guidance.
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL SAFETY General safety instructions Caution Special instructions Technical specs GRILL PROPERTIES OVERVIEW BEFORE USE USING YOUR GRILL Locking the lid Lid positions Height control Lid swivel Temperature probe Programs Timer Auto shut o Using your grill instructions 10-12 Temperature probe whist cooking HINTS AND TIPS... -
Page 4: General Safety
GENERAL SAFETY Carefully read all instructions, before operating the QUICKTIME GOURMET GRILL™ and save this manual for further reference. Do not attempt to use this appliance in any other way or any other purpose other than described in these instructions (intended use). Any other use, especially misuse, can cause severe injuries or damage by electric shock, heat, or fire. -
Page 5: Special Instructions
GENERAL SAFETY CAUTION: • This product is intended solely for indoor, non-commercial, non-industrial, household use in cooking/heating food for human consumption. Do not use the product outdoors or for any other purpose. • Do not allow the Power Cord to hang where it may be tripped over or pulled (e.g. over the edge of a table or counter), and do not allow the Cord to touch hot surfaces. -
Page 6: Grill Properties
GRILL PROPERTIES Handle Top Plate Release Button Upper Cover Hinge Base Oil Drip Tray Probe Storage Chamber Upper Grill Height Control Clip Lower Grill Bottom Plate Release Button Power Switch Control Panel Temperature Probe Program Area 15 Vegetables 21 Probe Button 26 Unit Button Display Area 16 Meat... -
Page 7: Overview
OVERVIEW Your new QUICKTIME GOURMET GRILL™ is perfectly suited for preparing a wide variety of delicate grilling dishes. Even thin pancakes, omelettes and wa les can be made on the flat grilling surface, while getting the typical grilling marks on the structured grilling surface OVERVIEW: •... -
Page 8: Before Use
BEFORE FIRST USE 1. Unpack the appliance and all accessories carefully. Check that no parts are damaged or missing. (Please check on page 4 to see you have all parts) 2. Remove all shipping materials and promotional materials, but DO NOT remove the model label. 3. -
Page 9: Using Your Grill
Do not attempt to apply any force for opening the lid to avoid damage. POSSIBLE POSITIONS OF THE LID: The QUICKTIME GOURMET GRILL™ can be used with the lid settled in three di erent positions; Closed Position Perfect for: Burgers / Boneless slices of meat / Fish / Vegetables / Grilling any combination of ingredients (e.g. -
Page 10: Height Control
Due to the swivel bearings of the lid, the lid can be adjusted parallel to the lower grilling surface, thus cooking your food evenly. NOTE: You cannot open the lid of the QUICKTIME GOURMET GRILL™ with the height control clip in the “LOCK” position. Before use, always slide the height control clip to the “OPEN” position first. Do not attempt to open the lid violently. -
Page 11: Programs
USING YOUR GRILL PRE-DEFINED PROGRAMS: 6 pre-defined programs are provided for various types of food, holding appropriate settings for the grilling temperature. Grilling Icon Range Used For Program Temperature 130 - 190°C All types of vegetables and fruit 160°C / 320°F Vegetables 270 - 370°F 200 - 240°C... -
Page 12: Using Your Grill Instructions
USING YOUR GRILL Turning On The Unit: First close the unit, unwind the power cord completely and insert the power plug into a grounded wall outlet, the operation panel shows the following figure. Press the power switch to turn on the grill which will display the following figure. The grill will began to preheat automatically to 200ºC unless another temperature is selected. - Page 13 USING YOUR GRILL Cooking Burger/Panini: When cooking burgers or paninis , you can select the preset Burger/Panini program (Icon Shown Below) and the automatic temperature selected will be 210ºC. You are able to increase or decrease the temperature by using the increase and decrease buttons if you do not wish to use the selected program.
-
Page 14: Temperature Probe Whist Cooking
USING YOUR GRILL Cooking Fish/Seafood: When cooking fish or seafood, you can select the preset Fish/Seafood program (Icon Shown Below) and the automatic temperature selected will be 230ºC. You are able to increase or decrease the temperature by using the increase and decrease buttons if you do not wish to use the selected program. - Page 15 TIPS AND HINTS SCAN ME FOR HELPFUL VIDEOS, RECIPES AND MORE HINTS AND TIPS FOR YOUR Scan this QR code or visit www.klevarange.com.au GRILLING MEAT AND FISH • For best grilling results, use cuts of meat of approx. 1 to 3cm. •...
-
Page 16: Cleaning
CARE & CLEANING NOTE: Do not use abrasive cleansers or metal scouring pads on any of the interior or exterior surfaces of the grill. These will scratch the surfaces and damage the non-stick coating on the cooking plates. Cleaning Your Grill: 1. -
Page 17: Solving Issues
SOLVING ISSUES PROBLEM POSSIBLE REASON SOLUTION The appliance doesn't react to your There may be fat on your finger tip or Wipe your finger tip with a moist cloth. input, only if you push hard. your skin is very dry. Then try again. - Page 18 SOLVING ISSUES PROBLEM POSSIBLE REASON SOLUTION Unexpectedly, the appliance does not “OFF” flashes on the touchscreen: For your safety, the appliance is equipped work any longer. The automatic shut-o has been with an automatic shut-o feature, that will triggered. be triggered after 1 hour of continuous use without any input.
-
Page 19: Error Messages
ERROR MESSAGES ERROR MESSAGE MEANING REQUIRED ACTION The upper grilling plate is missing The appliance can be operated only with both grilling plates or not installed correctly. installed properly. Ensure to insert and lock the upper grilling plate correctly. Ensure that the connectors on the underside of the grilling plate are clean, smooth, and undamaged without any corrosion. - Page 20 02 9387 4100 enquiries@klevarange.com.au Suite 301 / 209 Oxford St Kleva ® is a registered trademark Bondi Junction NSW 2022 Australia of Take Two Marketing and Events Pty Ltd.
