- Page 1 Owner’s Manual VERSION: RS01Z-EN-03 20V CORDLESS RECIPROCATING SAW Model RS01Z WARNING: To reduce the risk of injury, the user must read and understand the Owner's Manual before using this product. Save these instructions for future reference. support@mokeneye.com For Customer Service...
-
Page 2: Table Of Contents
operated (cordless) power tool. TABLE OF CONTENTS WORK AREA SAFETY GENERAL SAFETY WARNINGS ....2 • Keep work area clean and well lit. Cluttered or dark areas invite accidents. SAFETY WARNINGS FOR RECIPROCATING • Do not operate power tools in explosive SAW ............ -
Page 3: Safety Warnings For Reciprocating Saw
attached to a rotating part of the power tool BATTERY TOOL USE AND CARE may result in personal injury. • Recharge only with the charger specified by the • Do not overreach. Keep proper footing and manufacturer. A charger that is suitable for one balance at all times. -
Page 4: Symbols
meaning. Proper interpretation of these symbols will SYMBOLS allow you to operate the tool better and more safely. Symbol Designation/Explanation SAFETY SYMBOLS Volts The purpose of safety symbols is to attract your Amperes attention to possible dangers. The safety symbols and the explanations with them deserve your careful Hertz attention and understanding. -
Page 5: Get To Know Your Reciprocating Saw
GET TO KNOW YOUR RECIPROCATING SAW MOKENEYE 20V CORDLESS ANGLE GRINDER 1) PIVOT SHOE 2) TOOL-LESS BLADE CLAMP SLEEVE 3) LED LIGHT 4) VARIABLE-SPEED TRIGGER SWITCH 5) LOCK-OFF BUTTON 6) VENTILATION OPENINGS 7) HANDLE 8) SHOE-RELEASE SCREWS C20M1US C20MK1US VENTILATION OPENINGS... - Page 6 LOCK-OFF BUTTON BATTERY- REALEASE BUTTON VARIABLE-SPEED TRIGGER SWITCH ATTACH DETACH FUEL GAUGE 1/2" LED LIGHT...
- Page 7 PIVOT SHOE...
-
Page 8: Specifications
BLADE FACING DOWN BLADE FACING UP SPECIFICATIONS Model No. RS01Z Rated voltage 20V d.c. No-load speed 0 ~ 3000 SPM (Strokes per Minute) Stroke 1" (25mm) Sawing capacity in wood 4-3/4" (120 mm) Sawing capacity in aluminum 15/16" (24 mm) Sawing capacity in metal 3/4"... -
Page 9: Operating Instructions
NOTICE: If the charger does not charge the battery NOTICE: Please refer to the battery and charger pack under normal circumstances, return both the manuals for detailed operating information. battery pack and charger to your nearest Mokeneye Authorized Service Center for electrical check. FUEL GAUGE BATTERY PACKS •... - Page 10 After 30 minutes, reinsert the battery pack in the LED LIGHT charger. If the green LED continues to remain on, return battery pack to your nearest Mokeneye See FIG. 6 Authorized Service Center for checking or replacing. Your tool is equipped with an LED, located above the NOTICE: This situation only occurs when continuous blade clamp on the tool.
- Page 11 clamp and then hold it in place. c. Reinstall the battery and prepare to cut. b. Use the other hand to insert the saw blade into GENERAL CUTTING the blade clamp as far as possible. See Fig. 11 c. Release the tool-less blade clamp sleeve, and the blade should be locked in place automatically.
-
Page 12: Maintenance
As the blade starts cutting, raise the handle of MOKENEYE Factory Service Center or Authorized the tool slowly, until the shoe rests firmly on the MOKENEYE Service Station. -
Page 13: Trouble Shooting
MOKENEYE warrants to the original purchaser only, CLEANING that all MOKENEYE consumer POWER TOOLS will be free from defects in material or workmanship for a The tool may be cleaned most effectively with period of one years from date of purchase.
