Summary of Contents for Rifu Packaging Machinery RF-230
- Page 1 Instruction Manual...
- Page 2 Safety Information for Machine Operation I. Mechanical Specifications and Parameter. II. Installation. III. Functional Description and Troubleshooting. IV. Basic Operation and Application. V. Main Points of Simple Malfunction and Elimination Methods. Note： Please use and maintain this equipment strictly according to operation regulations of instruction manual ，...
- Page 3 I. Mechanical Specifications and Parameter External Dimension： View of ATL-650 Twin labeling maching...
-
Page 4: Label Specifications
2.Label specifications A clearance space of more than 2mm must be provided between labels in order to be scanned by electronic eye of labeler. 3. Specification of Power Supply： Voltage Specification ：AC220V±2%, 50 / 60HZ, Single-Phase； Power Consumption ：700W； 4. Printer Specification（Option item）： DH-7R Heat Coder ，... -
Page 5: Connection Of Power Supply
2. Connection of Electrical Box and Control Box： Connect the plugs /group sockets of electrical box and control box according to number of pins within the connector ， the sensitive electronic sensors is also connected and the electrical apparatus must be earth or grounded 3. - Page 6 MENU Next Page：The second can be entered when pressing “(Operation)” MENU The Second Next Page can be entered when pressing “Setting” :The third MENU The third MENU Label output frequency：it means the label speed, and it indicate the real-time speed of conveyor.Can not put data here.
- Page 7 One Label output:press “one label output” label head system output once label. It is use to test the label step motor. Labeling test: it is same to--one label output. Label delay:the sensor of object to start,delay the time (setting time)later,the step motor working off label output,labeling the object position where you want to.
- Page 8 3. label installment： Take extra caution on the position A and B as shown below (1)：Label flows direction when label winding is on the inside. (2)：Label flows direction when label winding is on the outside. When passing through label，please pull and loosen label paper appropriately and then tension the label paper with turning label wheel spindle C after passing through.
- Page 9 6. Adjust Electronic Sensor of Label： （User need not adjust it again because it has been adjusted before leaving factory in normal condition） ① When the label sensor aim at the label, turn the statoscope button of the sensor clockwise till red light off and yellow light on, and then turn the statoscope button anti-clockwise 360 °...
- Page 10 V. Main Points of Simple Malfunction and Elimination Methods Malfunction 1：Without Power Supply 9IS power supply switch on？ Is lamp bright after switch Is touch screen is light –up ? on power ? Is fuse broken ？ Malfunction on switching power supply Replacing fuse IS the plug-in unit of power supply inserted properly？...
- Page 11 Malfunction 2：Conveyor Belt is out of Work Is power supply switch-on ？ Press （Start） of the second Menu Is the conveying speed zero？ Malfunction of speed governor Is it in motion when pressing （ ↑ ） to change conveying speed？ Is the driving parts of conveyor Eliminate it belt has malfunction？...
- Page 12 Malfunction 3：Not Outputting Label： Electronic sensor has not scanned to Move electronic sensor position or adjust workpiece or electronic sensor is not sensitivity of electronic sensor in motion Labeler has not switched on or Starting up and adjusting speed of conveyor belt is not in motion conveyor belt Is the silicon wheel turned smoothly ?
- Page 13 Malfunction 4: Unable to Stop Labeler and Keys are Invalid IS electronic sensor detects workpiece all the time ? Main board has malfunction Sensor of work piece can scan conveyor belt or Move position of electronic sensor or adjust sensitivity of desquamation plate make electronic eye of electronic eye workpiece act.
- Page 14 Malfunction 6： More Labels Electronic sensor has more actions Adjust position or sensitivity of electronic sensor when inspecting single workpiece Setting of label length is overlong Reset length of label Readjust sensitivity label electronic sensor Malfunction 7：Label Paper may be Broken when Labeling Can workpiece be confronted by desquamation plate when conveyor Adjust position of labeler or protection fence...
- Page 15 Malfunction 8：Length of Label is Difference Precision of label length is not correct Please refer to clause 8 Adjust finely synchronous speed to make speed of label and Label has wrinkled when labeling pasting synchronous Adjust finely synchronous speed to make speed of label and Label is Slide downward when labeling it pasting synchronous Malfunction 9：Accuracy of Labeling Position is not Correct...
