- Page 1 ...because your out of your element, not out of your mind. User's Manual Installation Guide H1/G1 Heated Apparel with Microclimate Technology™...
-
Page 2: Table Of Contents
Atomic Skin™ Heated Apparel with Microclimate Technology™ Table of Contents Packing List Section...........................3 Safety Symbols and Important Information....................5 General Product Information........................6 Rules For Safe Operation...........................7 Product Description Section........................9 Jacket Liner Description........................9 Glove Liner Description........................10 Remote and Garment Controller Description..................11 Battery Harness Cable and Y-Splitter Description................12 Charging Cable and Dongle Description.....................13... -
Page 3: Packing List Section
Atomic Skin™ Heated Apparel with Microclimate Technology™ Packing List Section The following 12-volt heated apparel items are available from any Atomic Skin Heated Apparel dealer: Description Part Number Atomic Skin H1 Heated Jacket Liner................PHG-915 Above item includes: 1. Microclimate H1 Jacket Liner 2. - Page 4 Atomic Skin™ Heated Apparel with Microclimate Technology™ The following accessories may be purchased separately from any Atomic Skin Heated Apparel dealer: Replacement Garments: Part Number Jacket Liner w/ remote and controller unit; sizes XS - 3XL …....PHG-915 Jacket Liner w/o remote controller unit; sizes XS – 3XL …...... PHG-914 Glove Liner w/ controller unit;...
-
Page 5: Safety Symbols And Important Information
Atomic Skin™ Heated Apparel with Microclimate Technology™ Safety Symbols and Important Information Please read all the warnings and cautions that follow for proper usage of your Atomic Skin Heated Apparel. Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. -
Page 6: General Product Information
With our Atomic Skin Heated Apparel, riders can be warm with a single liner of apparel under normal riding gear that is controlled with a convenient wireless remote control. -
Page 7: Rules For Safe Operation
All of the 12-volt DC garments in the Atomic Skin H-Series Heated Apparel line may be used alone or in any combination with other Atomic Skin Heated Apparel garments, as long as they do not exceed the maximum amperage allowed by your motorcycle. - Page 8 Atomic Skin Heated Apparel must be maintained in accordance with the following instructions: Do not use this garment if there are any holes or exposed wires of any kind. • Do not crush the Atomic Skin Heated Apparel and avoid sharp folds when storing the • garments.
-
Page 9: Product Description Section
Product Description Section Jacket Liner Description Atomic Skin Heated Jacket Liners incorporate our Pro-Form™ outer shell. This ProForm shell is the result of years of development. This design offers climate protection and breathability in a stretchable, easy to wear garment. A heated fleece collar provides warmth along the top of the back and neck. The sleeve finishings reduce bulk around the wrist. -
Page 10: Glove Liner Description
Atomic Skin™ Heated Apparel with Microclimate Technology™ Glove Liner Description Atomic Skin Heated Glove Liners have been tested in all kinds of weather. The Carbon Nanocore panels incorporated in these glove liners were designed specifically for the hands and are comprised of bundled carbon-fiber strands that warm your fingertips with Far Infrared Rays—a safe slice of the energy spectrum... -
Page 11: Remote And Garment Controller Description
Remote Garment Controller The Atomic Skin Heated Apparel Remote is designed to be mounted on the wrist to allow for simple line of sight adjustment of heating gear. It maintains communication with the controller and manages the balance of heat between each garment. The simple two button interface allows the rider to quickly select one of five different comfort setting levels. -
Page 12: Battery Harness Cable And Y-Splitter Description
Battery Harness Cable Y-Spitter Cable The Battery Harness Cable is used to connect the Atomic Skin Heated Apparel to the vehicles electrical system. One Battery harness is needed for each rider. The Y-Splitter Cable is used to add a pair of Atomic Skin Heated Pants and Socks. -
Page 13: Charging Cable And Dongle Description
The Charging Cable is used for three operations: 1) Charging the battery on the Remote; 2) Communicating with the Atomic Skin App on a Smartphone and 3) it is used to download new firmware in the event he firmware needs to be upgraded. The Dongle is also needed to perform operation 2) Communicating with the Atomic Skin App on a Smartphone. -
Page 14: Installation Section
5. Connect the positive (+) wire from the Atomic Skin Heated Apparel Wiring Harness to the positive (+) battery terminal and then reconnect the vehicle’s positive (+) cable to the positive (+) battery terminal. - Page 15 Atomic Skin™ Heated Apparel with Microclimate Technology™ ! WARNING! Connecting Atomic Skin Heated Apparel to any other power source besides your vehicle’s 12-volt battery could damage the heating elements, void the warranty and may cause serious injury or death to the wearer.
-
Page 16: Connecting The Garment Controller To Jacket Liner
Atomic Skin™ Heated Apparel with Microclimate Technology™ Connecting the Garment Controller to Jacket Liner Installation Instructions: 1. Locate the female 6-Pin connector inside the jacket on the lower left near the bottom. 2. Push the controller all the way onto the connector... -
Page 17: Pairing Remote To Garment Controller
Atomic Skin™ Heated Apparel with Microclimate Technology™ Pairing Remote to Garment Controller To Pair the Devices: 1. Disconnect the garment from the power source. 2. To enter pairing mode: hold both buttons on the remote until all five (5) LED lights begin to flash. -
Page 18: Operation
Atomic Skin™ Heated Apparel with Microclimate Technology™ Operation Connecting the Jacket Liner to a Vehicle Connection Instructions: 1. To connect the jacket liner to the vehicle locate the male coax lead on the inside of the jacket liner near the lower left pocket. -
Page 19: Operation Section: Remote And Garment Controller Operation
Atomic Skin™ Heated Apparel with Microclimate Technology™ Operation Section: Remote and Garment Controller Operation Powering the System ON: To power on the remote press either the plus (+) or minus (-) button. System is ON Power the System OFF: To turn off the system hold the minus (-) button for two seconds until all lights turn off. -
Page 20: Adjusting The System Comfort Level
Atomic Skin™ Heated Apparel with Microclimate Technology™ Adjusting the System Comfort Level The Atomic Skin Heated Apparel system has five heat levels which allows the user to adjust the overall amount of heat in the garments. 1. To increase the heat levels press the plus (+) button. -
Page 21: Balancing The System Zones
Balancing the System Zones The Atomic Skin Heated Apparel system consists of four zones: the jacket, the gloves, the pants, and the socks. The ratio of heat between the jacket and the gloves or the pants and socks can be adjusted using the Zone Balance Feature. -
Page 22: Charging The Internal Battery On The Remote
Atomic Skin™ Heated Apparel with Microclimate Technology™ Charging the Internal Battery on the Remote A flashing LED in normal operation indicates a low battery. The Remote takes 12 hours to fully charge and is fully operation while charging. 1. Holding the plus (+) button will display the remaining battery level. -
Page 23: Stand-Alone Operation (Dead Battery On Remote Or Lost Remote)
Atomic Skin™ Heated Apparel with Microclimate Technology™ Stand-Alone Operation (Dead Battery on Remote or Lost Remote) If the remote is not available or the remote battery has died where charging is not available then the garment controller can still be used to power the system to half power. -
Page 24: Care And Storage
Atomic Skin™ Heated Apparel with Microclimate Technology™ Care and Storage Please follow the step-by-step instructions listed below to clean, store and care for your Atomic Skin Heated Apparel. To Clean Atomic Skin Heated Apparel 1. Disconnect garment from the power source. -
Page 25: To Store Atomic Skin Heated Apparel
To reduce the risk of damage to the heating elements that could cause burns, electric shock and fire, which could result in serious injury or death, the Atomic Skin Heated Apparel must be stored in accordance with the following instructions: Do not tightly compress the garments against or with sharp objects. -
Page 26: Trouble Shooting
Atomic Skin™ Heated Apparel with Microclimate Technology™ Trouble Shooting Performance of the Atomic Skin Heated Apparel is greatly affected by the fit of the garment, the condition of each electrical component, the wiring between the garment and the vehicle and amperage output potential of your vehicle’s electrical system. -
Page 27: Damaged Heating Elements
Damaged Heating Elements Damaged heating elements may cause garments to heat intermittently or completely fail to heat. Should your heating elements not operate properly contact your local Atomic Skin Heated Apparel dealer or call Atomic Skin for assistance. ! WARNING ! -
Page 28: Troubleshooting Chart
A damaged garment controller may cause garments to heat intermittently or completely fail to heat. Inspect the garment’s temperature control for damaged buttons or electrical connections. Should your controller not operate properly contact your local Atomic Skin Heated Apparel dealer for assistance. Troubleshooting Chart... -
Page 29: Technical Data
Atomic Skin™ Heated Apparel with Microclimate Technology™ Technical Data Product Specifications Product Description: Microclimate G1/H1 Heated Apparel Model Numbers: PHG-414 PHG-515 PHG-614 PHG-915 Country of Manufacture: Designed in USA, Made in USA and China Electrical Characteristics Input Voltage Range: 7... -
Page 30: Warranty
This limited warranty sets forth the complete liability and obligations of Atomic Skin Inc., and Coliant Corporation for breach of warranty. Neither Atomic Skin Inc., or Coliant Corporation shall not be liable for any damages directly or indirectly related to Atomic Skin Heated Apparel, including without limitation any damages for injury to persons or property occurring while anyone is wearing Atomic Skin Heated Apparel. - Page 31 Atomic Skin™ Heated Apparel with Microclimate Technology™ LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES, WRITTEN OR ORAL. TO THE EXTENT PERMITTED BY LAW, POWERLET DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE OR PURPOSE;...
- Page 32 Atomic Skin™ Heated Apparel with Microclimate Technology™ We have photos of all but the two last items but if we want drawings we will need these - Jacket liner – goes on page 8 • Glove liner – goes on page 8 •...
- Page 33 FCC STATEMENT: FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
