COAT TREE WALL
DESIGNED BY SIDSE WERNER
INSTALLATION MANUAL
46 cm
18.1"
VIEW2 ( 1 : 1 )
VIEW1 ( 1 : 1 )
VIEW4 ( 1 : 1 )
VIEW3 ( 1 : 1 )
VIEW1 ( 1 : 1 )
Mount the wall bracket on the
Material:
Title:
wall in the desired height.
Engineer:
Subject:
hkri
Creation date:
Drawing number:
12/02/2019
3200-000-04 ASSY Coat
General tolerances:
DS/EN 22768-1 m
Rack_G4-01
Recommended height is
C:\CAD\Workspace\FritzCAD\Afdelinger\Objects\Sidse Werner\Wall Coat Rack, 4G\04 Coat Rack_radius 40 bottom\3200-000-04
ASSY Coat Rack_G4.iam
146 cm/57.5´´ from the upper
bracket screw hole down to the
floor.
1
VIEW1 ( 1 : 4 )
B
A
Place each tube on the bracket
Paper size:
A4
according to the
letters (A, B, C, D).
Use a manual screw driver to
mount each tube with 2 screws.
Do not tighten the screws before
all tubes are placed on the brack-
et.
2
B
A
C
D
Please do not use electrical
screw driver to tighten the
screws.
2
C
D
VIEW1 ( 1 : 4 )
A
A
