Summary of Contents for ElectroPhonic Innovations One
- Page 1 Model One User Manual Page 1 of 13 v3.0...
-
Page 2: Bypass Mode
1 Welcome! Model One is unlike any other guitar. This guide will help you get started making music. As you learn your way around your guitar’s controls, creating inspiring tones will become second nature. Model One Features Specifically, your Model One includes the following: •... - Page 3 This is a great acoustic-type sound for strumming, fingerstyle, etc. and you can add DELAY and CHORUS effects - sweet! This is also the setting you can use to plug into an amp (like a regular electric guitar). AMP MODE Push the BYPASS button to enter AMP MODE.
- Page 4 We know that you probably don’t think that you need to read the manual, but we recommend that you at least skim it. The Model One is a versatile music creation tool whose subtle attributes can be overlooked if you max out the knobs and start banging away.
- Page 5 Players like Jimi Hendrix created amazing music by artfully controlling feedback and “riding the wave.” Manipulating your Model One’s controls allows you to shape this feedback and bring it in and out during performances. Experiment with the three knobs on the front of the guitar (PICKUP VOL, DRIVE, MASTER VOL) and the tone controls.
-
Page 6: Control Panel
3 Features and Functions – All the Cool Stuff That Makes the Model One Unique Let’s make this as simple as we can. There are 3 areas that require a few words. They are: • The guitar’s front knobs and toggle switch •... - Page 7 • Amp Controls • EQ • Delay • Chorus CONTROL PANEL – PREAMP 3.2.2 Each toggle switch has 3 positions that are labeled on the panel. • Toggle switch 1 has MOD, UK, and LUX settings • Toggle switch 2 has Overdrive – 1, Overdrive – 2, and Clean •...
- Page 8 Pushbut ton Pushbut ton Pushbut ton Pushbut ton CONTROL PANEL – DELAY 3.2.3 Push the illuminated switch to activate the DELAY module. Adjust the delay TIME, FBK (feedback/ repeats) and MIX (amount of delay). CONTROL PANEL – CHORUS 3.2.4 Page 8 of 13 v3.0...
- Page 9 Push the illuminated switch to activate the CHORUS module. Adjust the chorus DEPTH (pitch), LVL (amount/ mix) and SPEED (modulation rate). JACK BAY The JACK BAY is where the various inputs and outputs are located. The ON/OFF rocker switch is also here. Here you can interface with a smart phone, plug in headphones, and power your guitar with a DC power supply (wall wart).
- Page 10 This jack is mono. When a cable is plugged in, the speakers are muted. Note: The Model One has an active (powered) preamp so, even when playing through an amp or other similar device, the power on your guitar must be switched on.
- Page 11 5 A Word About Your Warranty Your warranty is voided if you open the Model One and tinker with it. This is not the end of the world, but you need to be aware of that if you want to change out any components.
- Page 12 Page 12 of 13 v3.0...
- Page 13 Industry standard for smart phone connectivity. Thank you for being part of this musical adventure! Model One is not like any guitar/amp you have experienced before… take your time and enjoy getting to know your Model One’s unique attributes. We are continuing to develop this concept. Your thoughts/input are welcome and encouraged…...
