Summary of Contents for EIBOS Oceanus
- Page 1 User Manual 【Resin 3D printing after process unit】 *Please read the manual carefully before using, and keep it properly.
-
Page 2: Before Using
■ When the product malfunction, please cut off power and contact with EIBOS or the distributor, do not try to fix it yourself. ■ Keep products and accessories out of reach of children. ■ This user manual can be modified without any prior notices. -
Page 3: Product Description
Product Description air inlet air outlet control panel cover sink window host water inlet water outlet power Packing List user manual X1 water pipe X2 power adapter X1 seal box X1 shelf board X1 *Factory installed... -
Page 4: Installation Instructions
Installation Instructions ① Take out the manual, water pipe, adapter and sealing box inside the product. ② Install the shelf board into the sink (factory installed). ③ Install the water inlet and outlet ,the other end into the bottom of the alcohol container. -
Page 5: Method Of Use
Method of Use 1.Plug in the power, the switch key flashes, and the device is in standby state. 2.Place the printed resin model in the sink.(It is not recommended to put the printer platform into the sink, otherwise the platform is easy to turn white. It is recommended to wash the printed resin model separately or using magnetic flexible steel plate) 3.Close the cover, press switch key, the operation... - Page 6 【Water Level】Press the water level key to switch to the appropriate water level according to the model height.Press the water level key for 8 seconds to forcibly drain water. 【 Washing 】 Press the washing key to set up the washing duration.
- Page 7 【NOTICE】 The mesh size of the shelf board is 14mm. Do not clean the model smaller than 14mm, otherwise it will fall into the cleaning component and cause damage to the model and device. 【NOTICE】 It is recommended to use alcohol or IPA as the cleaning solution, Water (no add, eg.
-
Page 8: Maintenance
2. For the IPA that has already been turbid, let the waste settle after standing for about 10 hours, and then slowly pour the upper layer of alcohol into other clean containers, which can increase the times of IPA use. Maintenance 1. - Page 9 position, as the result, the model is not completely dried.It is recommended to use longer duration of drying period for complicated models. Also, please face up the surface of the model that is not easy to dry as well as to tilt the model appropriately to avoid storing a large amount of cleaning fluid in the groove of the model.
- Page 10 After-sales Service Card Shenzhen EIBOS Chuanggou Tech Co.,Ltd Username Contact number Address Product Model Production Number Invoice Number Distributor ■ As a product warranty certificate, this card should be kept properly by customer. Do not change anything on this card.
