M60

Getting connected with your device

Table of Contents

Need help?

Do you have a question about the M60 and is the answer not in the manual?

Questions and answers

Summary of Contents for TOZED M60

Page 1 Getting connected with your device...
Page 3 Knowing the appearance and key functions of your device 1.Left Key 7.Call History 13.Mute 2.Direction Key 8.Configuration 14.Delete 3.Select Key 9.Volume Up 15.Number Key 4.Screen 10.External ANT 16.Quick Key 5.Right Key 11.Volume Down 17.Microphone 6.Contact 12.Power On/Off 18.Handfree Key 19.Dial Key...
Page 4: Connecting Your Device
Connecting your device To start using your device, connect your device as the following schematic diagram.
Page 5 Note:...
Page 6: Configuring Your Pc
Configuring your PC The following steps shows how to configure the Internet protocol in Windows10 system for WIFI connection. Go to Control Panel and find Network and Internet, and then go into Network and Sharing Centre. Select Change adapter settings.
Page 7 Find Wireless Network Connection and right click it, and then click Properties. In WiFi Properties, double-click Internet Protocol Version 4(TCP/IPv4), or select Internet Protocol Version 4(TCP/IPv4) and then click Properties.
Page 8 Select Obtain an IP address automatically, and Obtain DNS server address automatically. Click OK to confirm.
Page 9: Wireless Connection
Wireless connection Select the SSID on computer or mobile phone and click Connect. After inputting password, the WiFi can be used (default SSID and password can be seen on M60 sticker).
Page 10 Method 2: WPS Connect PC: Select the SSID on computer and click Connect as above. Press WPS Connect in M60 WPS Setting menu, and then your computer will connect to the SSID automatically without inputting password. Mobile Phone: Press WPS Connect in M60 WPS Setting menu, and then operate phone WLANà...
Page 11: Standby Status
Standby status Network signal strength Battery label WIFI signal Current network type 4G Calling forward open Connect power supply Missing calls In charging VoLTE active VoIP active...
Page 12: Web Configuration
Web configuration The device supports standard internet cable or WLAN wireless way to connect with computer or wireless devices. No matter what way to connect, please make sure to set the mode: obtain IP address as automatically. Please enter “192.168.8.1” in the IE browser after the computer obtain the IP address.
Page 13: Main Features
Main features 1. Main features on phone menu 1) Voice Call Calls Method#1. Pick up the handset or press the Handfree Key, then dial the number and wait for a few seconds or press the “ ”key. Dial Method#2. Dial the number then press the “ ”key.
Page 14: Call History
Down Key to change the volume. Press the Mute Key so that other side cannot hear your voice, press Mute Key again to cancel mute. In idle screen, press Configuration Key àSelect Call Call setting Setting. 2) Call History Press Call History Key to enter the Call History Menu as follows. Top level menu Secondary menu Remark...
Page 15 3) Contact Press Contact Key to enter the Contact menu as follows. Top level menu Secondary menu Remark Browse Browse contacts Create contacts Contact Search Search contacts Delete All Delete all contacts Memory Space Contacts details...
Page 16 4) Configuration Press Configuration Key to enter the Configuration menu as follows. Secondary menu Remark Top level menu LCD setting Setting backlight Set volume, ring type, ring Sound setting volume etc. Set update time and time Time setting format Configuration Network setting Set APN Hotline config, Dial Delay...
Page 17: Router Function
5) Router Function Secondary menu Remark Top level menu WiFi status WiFi Status WiFi Switch Open/Close WiFi Router functions WiFi setting Set SSID, WPS setting etc. Setting local IP, DHCP DHCP setting switch, senior setting...
Page 18: System Info
6) System Info Top level menu Secondary menu Software Version Voice status Hardware Info System Info Model Version Battery MAC Address Running time...
Page 19: Quick Dial
7) Quick Dial M60 provides 8 quick keys to make quick dial. Before using this function, please setting quick key number as follows. * If you have not set quick key number before, you can press the Quick Key à...
Page 20: Port Forwarding
Main features on WEB UI 1) Port Forwarding Log into the WEB UI. Select Port Forwarding in Firewall Settings menu, and then set port forwarding.
Page 21: Ddns Settings
2) DDNS Settings Log into the WEB UI. Select DDNS Settings in Advanced Settings menu(Devices SettingsàAdvanced Settings), and then set DDNS parameters.
Page 22: Warning And Notice
Warning and notice · Do not insert SIM card when the device is powered up. Please power off the phone if long time non-use the phone.
Page 23 · Use original power adapter and battery, or accessories that authorized by Tozed, otherwise it may damage the device or cause dangerous. · Do not put the phone in the sunlight or high temperature place, it may cause explosion due to high temperature of battery.
Page 24 Menu Features on M60 Call Sent Outgoing calls Call Missed Missed calls Call Received Incoming calls Call Sent Erase outgoing call history Call Received Erase incoming call history Erase Calls Call Missed Erase missed call history All Calls Erase all call history...
Page 25 Display Wifi Status switch/SSID/Broadcast/security/current Access&Channel Numble Status:ON Open Wifi Wifi Switch Status:OFF Close Wifi SSID Change SSID name Main SSID OPEN Activate Broadcast SSID Broadcast CLOSE Deactivate Broadcast SSID Select bandwidth.Default should be "20M Bandwidth ONLY" Wifi Setting Advanced Settings Select Wi-Fi channel.Default should be Channel "Auto"...
Page 26 Customer Service Hotline: 117 100 100 Email: techsupport@dialog.lk General Office Dialog Broadband Networks (Pvt) Ltd. (PV 261) No. 475, Union Place, Colombo 02 Sri Lanka Tel +94 117 100 100 / FAX + 94 117 100 701 www.dialog.lk...
Page 27: Legal Information
LEGAL INFORMATION © Copyright 2019 TOZED CORPORATION. All rights reserved. We reserve the right to amend the technical parameters of the user manual. We will improve this user manual and adjust the printing errors in time without notification in advance.
Page 28 Terms and Conditions of After Sales Warranty In the event of a malfunction or defect, Dialog Broadband Networks (Private) Limited (Company No. PV 261)(“Company”), shall at its absolute discretion either repair or replace this Router (within a period of twelve (12) months)(extendable for 2-3 years on extra cost), the Antenna (within a period of six (6) months) and 12V Eternal Power Adapter (within a period of six (6) months)(collectively “Equipment”) free of charge from the date hereof.
Page 29 The customer removes, defaces or alters on the serial numbers in the Equipment or otherwise tamper with the Equipment; In the option of the Company, the Equipment has been damaged through wear and tear, accident, misuse, neglect, alteration, modification, repairs attempted by anyone other than an authorized agent of the Company, corrosion, dust, unsuitable electricity supply, animals or insects, improper or faulty installation or caused by program, data, virus, spyware,...
Page 30 Only the original purchaser whose name appears on this warranty card can claim under this warranty. The Company’s only obligation shall be to repair or replace the Equipment as set out herein and shall not be liable for any damage, lien, charge or otherwise.
