  • Page 1 Digital Multimeter USER GUIDE...
  • Page 2 For the fuse, it must be replaced with an identical model if necessary. For the concrete specification, please see the clause of maintenance or label on the instrument board. Safety Symbols AC voltage/current DC voltage/current Diode Hazardous Voltage Buzzer Ground connection Risk Of danger Double insulation Low battery indication Digital Multimeter www.ultrics.uk...
  • Page 3 Store temperature: -10° C - 50° C; The relative humidity: <85 % Temperature of precision: 23° C+5 C°; The relative humidity: <75 % Specification 1. DC Voltage Range Accuracy Resolution 200mV 100uV (0.5%+2) 10mV 200V 100mV (0.8%+2) 600V Input impedence: 1MΩ Digital Multimeter www.ultrics.uk...
  • Page 4 Indicate forward voltage drop of diode unit: k Ω 6. Transistor hFE Test Range Test Current Test Voltage Test Range 0-10000 1b=10uA Vce=3V NPN & PNP 7. Continuity test Test voltage approximate 2.8V, current 1.5mA The buzzer will beep when conductance resistance approximate<30 Digital Multimeter www.ultrics.uk...
  • Page 5 4. Read the measured current on the display Caution: a. Do not measure current that exceeds the MAX value as indicated in the specifications; b. Do not input voltage exceeds 36V DC or 25V AC when you are at the setting of measuring current. Digital Multimeter www.ultrics.uk...
  • Page 6 3. Read the approximate hFE value at the test condition of base current 10uA and Vce 3V. (7) Replacing the Battery sign displayed on the screen indicates requirement for battery replacement. Be careful to observe battery polarity. Digital Multimeter www.ultrics.uk...
  • Page 7 Disconnect the test leads from the circuit before changing the mode. This user manual is also available in these languages French German Italian Polish Dutch Spanish Swedish You can download the user manual in your preferred language from our website (ultrics.uk) in forms of eBook. Digital Multimeter www.ultrics.uk...
