Operating and mounting instructions
General instructions and technical details
TUBUS TC and TC-S
Safety Dampers
Compact powerhouse
Crane installations
Energy capacity 630 Nm/cycle to 17,810 Nm/cycle
Maximum stroke 30 mm to 198 mm
TC
TC-S
The identification numbers listed are the
respective standard units of the corresponding
damper series. Special types can have deviating
identification numbers.
21_22_0019 Issue 05.2022
Stand 03.2021
Profile Body
Mounting Screw
ACE Stoßdämpfer GmbH · Postfach 1510 · D-40740 Langenfeld · T +49 (0)2173 - 9226-10 (Technik -20) · F +49 (0)2173 - 9226-19 · info@ace-int.eu · www.ace-ace.com
Table of contents
Page
General instructions ................................. 2
Safety information ................................... 2
Intended use ........................................... 2
Description and function ........................... 2
Calculation and design ............................. 2
Delivery and storage ................................ 2
Maintenance and care .............................. 2
Disassembly and disposal ......................... 2
Mounting instructions ................................ 3
Warranty ................................................. 4
Expected service life ................................. 4
Technical data .......................................... 4
ACE Stoßdämpfer GmbH · www.ace-ace.com
Advertisement
Related Manuals for STABILUS ACE TUBUS TC
Summary of Contents for STABILUS ACE TUBUS TC
- Page 1 Operating and mounting instructions General instructions and technical details TUBUS TC and TC-S Safety Dampers Compact powerhouse Crane installations Energy capacity 630 Nm/cycle to 17,810 Nm/cycle Maximum stroke 30 mm to 198 mm TC-S Table of contents Page General instructions ......... 2 Safety information ........
- Page 2 TC and TC-S Safety Dampers (crane installations) Manual General instructions Calculation and design Example: In order to ensure an optimum, fault-free and durable function of Type TC90-49 characteristic curve This manual is for the disruption-free use of the product the TUBUS Profile Dampers they must be correctly dimensioned types listed on page 1;...
- Page 3 TC and TC-S Safety Dampers (crane installations) Mounting instructions and mounting accessories Installation instructions TC and TC-S WARNING Before installation and use check whether the identification A failure of the product can lead to personal injuries and/or number on the damper or on the packaging matches the material damage.
- Page 4 TC and TC-S Safety Dampers (crane installations) Manual to 1 million load changes is to be expected. Warranty Technical data Fundamentally, all modifications to the product by third parties Energy capacity: 630 Nm/cycle to 17,810 Nm/cycle lead to exclusion from the warranty. Energy absorption: 31 % to 64 % Obvious defects must be reported to the vendor in writing immedi- Dynamic force range: 80,000 N to 978,000 N...
